Baolian Green color three terminal microswitch microswitches for arcade push button

Product Overview

Description

Baolian Green color three terminal microswitch microswitches for arcade push button





Specification:



1. rating: 5A, 125/250 VAC

2. operating frequency (mechanical): max. 120 operations per minute

3. operating frequency (electrical): 10~30 operations per minute

4. initial contact resistance: Max.30mΩ

5. insulation resistance: Min. 100mΩ (500VDC/minute)

6. initial dielectric: 1000VAC (50-60HZ)/minute between contacts, 1000VAC (50-60HZ)/minute between live parts and dead metal parts

7. service life (mechanical): Min. 10,000,000 operations

8. operating temperature:0~85 centigrade

9. storage temperature: -25~85 centigrade



 Features:

*ColorGreen

*Usage:HAPP style push button,small round push button,1P 2P push button ect.
