Kaishan brand small rocky layer hardrock drilling rig machine
Kaishan brand small rocky layer hardrock drilling rig machine
Kaishan brand small rocky layer hardrock drilling rig machine
Kaishan brand small rocky layer hardrock drilling rig machine
Kaishan brand small rocky layer hardrock drilling rig machine
Kaishan brand small rocky layer hardrock drilling rig machine
Kaishan brand small rocky layer hardrock drilling rig machine

Kaishan brand small rocky layer hardrock drilling rig machine

Share on (1600232986702):


Price:$12,400.00 - $14,350.00

Quantity:


Product Overview

Description









Model
Aperture
Air consumption
Engine power
Size (mm)
Weight (KG)
KG310
φ80-105 mm
7-15m³/min
33.1kw /2400 r/min
4650*2000*2200
4000
KG310H
φ80-105 mm
7-15m³/min
33.1kw /2400 r/min
4650*2500*2200
4200
KG320
φ80-105 mm
7-15m³/min
59kw /2400 r/min
6050*2360*2700
4500
KG320H
φ80-105 mm
7-15m³/min
59kw /2400 r/min
6050*2360*2700
4700
KG410
φ90-115 mm
10-17m³/min
59kw /2400 r/min
6150*2350*2700
4500
KG410H
φ90-115 mm
10-17m³/min
59kw /2400 r/min
6150*2350*2700
4700
KG420
 φ90-152 mm
13-20m³/min
58kw /2200 r/min
5900*2250*2700
5200
KG420H
 φ90-152 mm
13-20m³/min
73kw /2200 r/min
6200*2250*2700
5700
KG420S
φ90-152 mm
13-20m³/min
58kw /2200 r/min
Motor(55kw /1460 r/min)
6400*2250*2700
5800
KG420SH
φ90-152 mm
13-20m³/min
(58kw /2200 r/min) Motor(55kw /1460 r/min)
6400*2420*2700
6100
KG430
φ90-152 mm
13-20m³/min
58kw /2200 r/min
6300*2250*2700
5250
KG430H
φ90-152 mm
13-20m³/min
73kw /2200 r/min
6300*2400*2700
5700
KG430S
φ90-152 mm
13-20m³/min
58kw /2200 r/min/
Y250M-4(55kw/1460r/min)
6700*2200*2700
6000
KG430SH
φ90-152 mm
13-20m³/min
58kw /2200 r/min/
Y250M-4(55kw/1460r/min)
6700*2400*2700
6200
KG510
φ105-152mm
13-22m³/min
58kw /2200 r/min
6800*2200*2850
6500
KG510H
φ105-152mm
13-22m³/min
58kw /2200 r/min
6800*2450*2850
7000
KG520
φ105-152mm
15-22m³/min
73kw /2200 r/min
6800*2200*2850
6500
KG520H
φ105-152mm
15-22m³/min
73kw /2200 r/min
6800*2250*2850
7000
KG590
φ105-152mm
15-22m³/min
73kw /2200 r/min
7100*2300*2700
7000
KG590H
φ105-152mm
15-22m³/min
73kw /2200 r/min
7100*2500*2700
7200
KG610
φ105-202mm
15-26m³/min
92kw/2200r/min
6700*2250*2850
7100
KG610H
φ105-202mm
15-26m³/min
92kw/2200r/min
6700*2800*2850
7600
KG726Ⅲ
 φ90-115 mm
9-17m³/min
59kw /2400 r/min
5600*2400*2300
4200
KG726HⅢ
 φ90-115 mm
9-17m³/min
59kw /2400 r/min
5600*2600*2300
4400
KG920BⅢ
φ90-115 mm
9-17m³/min
59kw /2400 r/min
5600*2400*2300
4200
KG920BHⅢ
φ90-115 mm
9-17m³/min
59kw /2400 r/min
5600*2600*2300
4400






















Q1: Are you factory or trade company?
A1: We are factory. And we have ourselves trading company.

Q2: What the exactly address of your factory?
A2: Our company is located in No. 201, Building 23, No. 28 Yulong Road, Quzhou City, Zhejiang Province

Q3: Warranty terms of your machine?
A3: One year warranty for the machine and technical support according to your needs.

Q4: Will you provide some spare parts of the machines?
A4: Yes, of course.

Q5: What about the voltage of products??Can they be customized?
A5: Yes, of course. The voltage can be customized according to your equirement.

Q6: Which payment term can you accept?
A6: 30% T/T in advanced, 70% T/T against the B/L copy.

Q7: How long will you take to arrange production?
A7: Normally, spot goods are delivered within 7-15 days, while customized products need to be delivered within 25-35 days

Q8: Can you accept OEM orders?
A8: Yes, with professional design team, OEM orders are highly welcome.

Q9: Which trade term can you accept?
A9: Available trade terms: FOB, CIF, CFR, EXW, CPT, etc.
