Xilin 1.5ton 3300lbs 177inch full electric walkie stacker for sale
Xilin 1.5ton 3300lbs 177inch full electric walkie stacker for sale
Xilin 1.5ton 3300lbs 177inch full electric walkie stacker for sale
Xilin 1.5ton 3300lbs 177inch full electric walkie stacker for sale
Xilin 1.5ton 3300lbs 177inch full electric walkie stacker for sale
Xilin 1.5ton 3300lbs 177inch full electric walkie stacker for sale
Xilin 1.5ton 3300lbs 177inch full electric walkie stacker for sale

Xilin 1.5ton 3300lbs 177inch full electric walkie stacker for sale

Share on (1600233651007):


Price:

Quantity:


Product Overview

Description













Model
CTDR10-III
CTDR12-III
CTDR15-III
Capacity
Q（kg）
1000
1200
1500
Load centre distance
c（mm）
500
500
600
Load distance, centre of drive axle to fork
x（mm）
795
795
795
Fork height, lowered
h13（mm）
70
70
70
Height, mast lowered
h1（mm）
2145/1895/2145/2295
Max. lift height
h3（mm）
1600/2500/3000/3300
Height, mast extended
h4（mm）
2145/3145/3645/3995
Overall length
l1(mm
2015
2015
2095
Length to face of forks
l2(mm)
890
890
970
Overall width
b1(mm)
1182-1582
1182-1582
1182-1582
Fork dimensions
s/e/l(mm)
35/100/1070(1150)
35/100/1070(1150)
35/100/1070(1150)
Width overall forks
b5(mm)
200-800
200-800
200-800
Aisle width for pallets 800x1200lengthways
Ast(mm
2420
2420
2500
Turning radius
Wa(mm)
1575
1575
1655
Travel speed, laden/unladen
Km/h
5.3/5.6
5.3/5.6
5.8/6(AC)
Lifting speed, laden/unladen
m/s
0.11/0.17
0.1/0.16
0.09/0.16
Battery Voltage, normal capacity K5
V/Ah
24/120
24/120
24/200
Truck weight
kg
760/780/800/825
780/800/820/845
940/960/980/1005












Q1:Are you a factory?
A1: Of course.Ningbo Ruyi Joint Stock Co. Ltd., established in 1985, is a national hi-tech enterprise, which owns the unique
combination of scientific research,development, production, sale and service. Moreover, the trademark of Xilin has been registered in 68 countries and regions around the world and its products sell well in more than 100 countries and regions until this year.
Q2: Do you have agent or representative abroad?
A2: Yes. We have two branches in the US and Russia. We have two warehouses are located in Los Angles and Chicago with products in stock and ready to ship. We also have Xilin distributors agent in Norway, Thailand, Japan, Vietnam and Malaysia. If you are interesting to be our agent and enjoy more price. Pls contact us then we can discuss more detailed.
Q3: What's the specification of the chargers?
A3: Xilin have all kinds of the chargers and welcome the customers to custom-made.
Q4: Warranty for the product?
Q4：We do offer one year warranty which would cover the failure not caused by miss-usage like over loading or misplacing the item.And There is no warranty for wearing parts such as wheel and fuse.
Q5: How about the delivery time?
A5: Usually Xilin producing time is 15-20 working days after we receive the advanced payment. For some standard products,we have most in stock and could delivery immediately.
Q6:What is your payment term?
A6: T/T or L/C,if you want any other way,please contact us.
Q7: What can I get from cooperating with Xilin?
A7: 1. Unique products, with customized service.2. Timely production and delivery, time is money. 3. Market protection service, long term business strategy.
