Buy Bentonite Cat Litter Making Machine/cat Litter Production Line Granulator Fertilizer Machine Round Ball Pellet Wet Process

Product Overview

Description

 Humin Rich Humate Granule Machine/Potassium Humate Granulator Machine/pan granulator





Description for fertilizer making machine



Fertlizer making machine is the main equipment to make the powder form material into ball, mainly used in the cement industry, steel industry and compounded fertilize industry.The ferilizer making machine is one of common equipments in compound fertilizer industry.

Generally, it is applicable to smaller scale fertilizer production of medium, and low concentration. The slope degree of its pan can be adjusted from 35°to 55°.The pan revolves at a certain angle with the horizontal plane driven by the motor through reducer.The powder will rise along with the revolving pan under the friction between the powder and the pan, on the other hand, the powder will fall down under the function of its gravity. The powder material rolls in a certain trace under the function of these three forces.

The feature for fertilizer making machine

1. Overall disc structure, granulation rate reaches above 93%.

2. The reduction gears and motor using the flexible belt driving, smooth start, slowing impact, extend equipment service life.

3. The disc bottom adopts multiple steel plates which are firm, durable, not deforming.

4. The granulator disc lining adopts the high strength glass steel which is antiseptic and durable.

Parameter for fertilizer making machine

Model	Inner diam  (mm)	Side height  (mm)	Rotation speed  ( r/min )	Motor power  ( kw )	capacity
HY16	1600	300	20	3	0.4-1(t/h)
HY18	1800	300	18	3	0.6-1.2(t/h)
HY20	2000	350	16	4	0.6-2.0(t/h)
HY22	2200	360	15	5.5	0.8-2.2(t/h)
HY25	2500	380	13.5	5.5	1-2.5(t/h)
HY28	2800	400	13	7.5	1-3.0(t/h)
HY30	3000	420	12.5	11	1-4(t/h)
HY32	3200	450	12.5	15	1-5.0(t/h)
HY35	3500	460	12	18.5	1.5-5.5(t/h)
HY36	3600	460	12	18.5	2-6.0(t/h)
