Portable data collector wireless 4g rugged android 9.0 qr code scanner pda for Retail Industry (A version)
PS: Dear all, price show on page is for T80 A version,if need B version or C version, plz inquiry us then we can quote price and draft order link for you accordingly, thanks!
A version without profession barcode scanner
B version with honeywell N4313 1D barcode scanner
C version with honeywell N3603/N6603 2D qr code scanner
Details description:
1.Based on android 9.0 platform, user-friendly interface, and a long lifecycle that matches that of the
traditional T80.
2.Reduces user fatigue by offering all of the functionality needed in an easy -to-carry from factor.
3. Allows mobile workers to seamlessly interact with data in virtually any lighting condition.
4. Durable construction and sealing deliver reliable operation and maximize worker uptime.
5.Delivers full wireless coverage for applications inside and outside of the four walls,allowing real-time access to critical data.
6.Delivers fast business transactions, allowing workers to complete multiple tasks quickly.
7.Provide functions test demo and the SDK code very easy to developed your Application .
8.Application fields: Supermarkets, clothing industry, Logistics/warehouse management, Police, Postal services, Urban management, Tobacco.
Specification for portable scanner pda T80
PHYSICAL CHARACTERISTICS | ||
Dimension and Weight | 166 x 77.5x 22mm | |
Display and Touch Panel | 4.5'' WVGA (480*854), 650000 colors Rugged dual touch capacitive touch panel | |
Power | Main battery: Li-ion, rechargeable, 4200mAh | |
Expansion Slot | 2* PSAM (Optional): ISO7816 protocol , 1 SIM, 1 MicroSD (TF) slot | |
Interfaces | Type -C USB | |
Keypad | 21 pcs soft silicon key | |
AC Adapter | Input: 100V-240V, 50-60Hz, 0.29A ,Output: 5V, 2A | |
PERFORMANCE CHARACTERSTICS | ||
CPU | Cortex A-53 2.0 GHz quad-core | |
Storage | RAM+ROM: 2GB+16GB | |
Operating System | Android 9.0 | |
USER ENVIRONMENT | ||
Operating Temp. | -20°C to 55°C | |
Storage Temp. | -25°C to 70°C | |
Humidity | 5%RH - 95%RH non condensing | |
Drop Specifications | Multiple 1.5m drops to concrete across the operating temperature range | |
Sealing | IP66 | |
Developing Environment | ||
SDK | Software Development Kit | |
Language and Tool | Java,Eclipse / Android Studio | |
DATA COMMUNICATION | ||
WWAN | 4G:TDD -LTE (B38 ,B39,B40,B41) FDD-LTE (B1,B3) | |
3G:WCDMA 850/900/1700/1900/2100MHz | ||
2G: GSM/dege/GPRS 850/900/1800/1900MHz | ||
WLAN | IEEE802.11 a/b/g/n, 2.4G/5G dual-band, internal antenna | |
blue tooth | Support BT2.0 +EDR/3.0 +HS/4.1+HS,Transmission distance is 5-10m | |
GNSS | GPS/AGPS, internal antenna | |
BARCODE READER(OPTIONAL) | ||
1D Linear Scanner | Honeywell N4313 Symbol 955 Minde966 | UPC/RAN,Code128 ,Code 39 ,code 93.Code11 ,Interleaved 2 of 5 ,Discrete 2 of 5 ,Chinese 2 of 5 ,Codabar ,MSI,RSS |
2D imager scanner |
Honeywell N6603 Honeywell N3603 Newland 3096 | PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode, Postal Codes, US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX). etc. |
COLOR CAMERA | ||
Resolution | 8MP autofocus camera with flash | |
NFC (optional) | ||
Frequency | 13.56MHz | |
Protocol | ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc. | |
ACCESSORIES | ||
Standard | AC Adapter,,USB cable,Cradle (Optional) |
Q: Are you manufacturer?
A:Yes,we are manufacturer profession in thermal printer,pos machina,barcode scanner etc;
Q:Would you provide SDK for me?
A:Yes,we offer free SDK if order sample.
Q:What is the minimum order portable scanner pda?
A: one sample order is acceptable,if require OEM.We can confirm further.
Q:What the after sale service portable scanner pda?
retail industrial android pda
a.Our all products will provide 1 year warranty.
4g scanner
b.if there is no Man-made problem,we will replace or repair for your freely.1% extra device and spare parts will be provided when bulk order portable scanner pda
retail industrial android pda
Q:How will you provide technical support?
A: 7*24 Online support. If necessary, on site support will be offered.
Q:What payment methods you accept?
A: T/T, Western Union, Paypal, Alibaba trade assurance, Cash etc
