YK 60 Oscillating Granulator for Wet Type Powder,YK 60 Swaying Granule Making Machine,YK 60 Oscillating Pellet Mill
- Category: Granulators >>>
- Supplier: Shanghai Lao Le Machinery Equipment Co. Ltd.
Share on (1600239640034):
Product Overview
Description
Product introduction
The swing granulator is used to make the wet powder into the required particles, and can also crush the bulk dry materials to the required particles.
1. the machine is a swing action of rotating cylinder. Through screen, wet powder can be prepared into particles without raw materials, and can also be widely used for crushing the pressed blocks and becoming ready-made particles.
2. in chemical medicine, the powder used as mixed powder is not developed into particles, dried for pressing tablets, and can also crush blocks condensed during storage or formed blocks during chemical processing. It is used in the planning of food industry zone to treat candy and sugar mixture and wheat tooth milk, etc. in other industries, such as ceramics, plastics and other mixtures become molding particles.
3. it is not suitable for solid, fluidity, slurry or grinding.
4. The machine has a screen. The mesh screen number should be determined according to the particle size requirements. Please tell us to install it
Main features: the screen is easy to install and dismantle, and it can also be adjusted and tightened properly. The seven angle drum is easy to disassemble and easy to clean. The mechanical transmission system is all enclosed in the body, and it is equipped with lubrication system, and the whole machine runs smoothly. The speed of the type-7 rotary drum can be adjusted. It is a new type designed and manufactured according to GMP requirements of drug production. The whole machine is sealed with high quality stainless steel plate. Make the whole machine clean and beautiful, especially the screen adopts metal mesh or stainless steel plate mesh. The quality and economic efficiency of the particles are greatly improved.
1. the machine is a swing action of rotating cylinder. Through screen, wet powder can be prepared into particles without raw materials, and can also be widely used for crushing the pressed blocks and becoming ready-made particles.
2. in chemical medicine, the powder used as mixed powder is not developed into particles, dried for pressing tablets, and can also crush blocks condensed during storage or formed blocks during chemical processing. It is used in the planning of food industry zone to treat candy and sugar mixture and wheat tooth milk, etc. in other industries, such as ceramics, plastics and other mixtures become molding particles.
3. it is not suitable for solid, fluidity, slurry or grinding.
4. The machine has a screen. The mesh screen number should be determined according to the particle size requirements. Please tell us to install it
Main features: the screen is easy to install and dismantle, and it can also be adjusted and tightened properly. The seven angle drum is easy to disassemble and easy to clean. The mechanical transmission system is all enclosed in the body, and it is equipped with lubrication system, and the whole machine runs smoothly. The speed of the type-7 rotary drum can be adjusted. It is a new type designed and manufactured according to GMP requirements of drug production. The whole machine is sealed with high quality stainless steel plate. Make the whole machine clean and beautiful, especially the screen adopts metal mesh or stainless steel plate mesh. The quality and economic efficiency of the particles are greatly improved.
Technical parameters of YK-60 rocking granulator: | |||||||
roller diameter | 60 mm | ||||||
throughput | 20-30 (kg / h) | ||||||
Swing range | >360 (degrees) | ||||||
Rolling and rocking times | 46 times / min | ||||||
Feed port | 209×212 | ||||||
Motor power | 0.55 kw | ||||||
Voltage | 220V | ||||||
weight | 60kg | ||||||
Dimensions | 320 * 560 * 600 (mm) | ||||||
