Highly qualified 405nm 450nm473nm 488nm laser blue red dot line pointer diode laser blue
- Category: >>>
- Supplier: Elite Optoelectronics Co. Ltd.Elite Ltd.
Share on (1600240476352):
Product Overview
Description
Specification | Industrial Diode Laser Module | ||||||||||||
Wavelength | 780nm | 808nm | 830nm | 850nm | 905nm | 940nm | 980nm | ||||||
Output Power | 1,5,10,20,35,50,80,100,and130mW（Custom） | ||||||||||||
CDRH Class | I,II,IIIa,IIIb | ||||||||||||
Aperture | Ø1.0mm,Ø1.5mm,Ø2.0mm,Ø2.4mm,Ø3.0mm,Ø5.0mm,Ø6.0mm | ||||||||||||
Divergence | 0.1mrad,0.2mrad,0.3mrad,0.5mrad,0.8mrad,1.0mrad | ||||||||||||
Circular Beam Size | Ø0.5mm(@0.5m),Ø1.0mm(@1m),Ø4.0mm(@5m),Ø5.0mm(@10m) | ||||||||||||
Elliptical Beam Size | 1x2mm(@1m),2x4mm(@2m),3x6mm(@5mm),5x10mm(@10m),8x16mm(@20m） | ||||||||||||
Operaating Current | <300mA | ||||||||||||
Input Voltage | 3.0to5.0V,9.0V,12.0V,24.0V | ||||||||||||
Operating Temperature | -20℃~60℃ | ||||||||||||
Storage Temperature | -40℃~85℃ | ||||||||||||
MTBF | >10,000hours | ||||||||||||
1.Small beam size from 5um 2.Compact and light weight
3.Long term stability 4.High reliability
5.High power density 6.Water-resistant IP55~65
Elite offers the ultra-small beam laser diode module,specially designed for high precision instrumrnt and equipment,widely used in precise positioning and high-precision detection.
FAQ
1. What's the way of shipping
Shipping via DHL, TNT, UPS, FedEx, and EMS.
2. What's the payment method?
Assurance payment on Alibaba
3. What's your MOQ?
1 Piece
4. What's the delivery time?
3 – 7 days for International Shipping
5. Can I customize the products based on my requirements?
Yes. We can design and produce lasers based on your special requirements.
6. Do you have any certifications for lasers?
Yes. All our lasers are certified with CE, RoHS.
7. How long is the warranty period?
12 months.
Shipping via DHL, TNT, UPS, FedEx, and EMS.
2. What's the payment method?
Assurance payment on Alibaba
3. What's your MOQ?
1 Piece
4. What's the delivery time?
3 – 7 days for International Shipping
5. Can I customize the products based on my requirements?
Yes. We can design and produce lasers based on your special requirements.
6. Do you have any certifications for lasers?
Yes. All our lasers are certified with CE, RoHS.
7. How long is the warranty period?
12 months.
