HBRVD 187.5 Electric Brinell Rockwell Vicker universal hardness tester
- Category: Physical Measuring Instruments >>>
- Supplier: Jinan Bojan Testing Machine Co. Ltd.
Share on (1600242576124):
Product Overview
Description
Product Overview
Electric Brinell Rockwell Vickers hardness tester
The Electric Brinell Rockwell Vicker hardness tester is equipped with three test methods of Brinell, Rockwell and Vickers, and a multi-purpose multifunctional hardness tester with seven-level test force, which can meet the requirements of users for various hardness tests. The application of test force, load holding and unloading are automatically completed. It has a wide range of use and convenient operation. It is a hardness testing machine that is often used by industrial and mining enterprises and scientific research institutions.
Hardened steel, surface hardened steel, hard alloy steel, cast iron, non-ferrous metals, various quenched and tempered and annealed steels, hardened thin steel plates, also suitable for softened metals, surface heat treatment and chemical heat treatment, etc.
Hardened steel, surface hardened steel, hard alloy steel, cast iron, non-ferrous metals, various quenched and tempered and annealed steels, hardened thin steel plates, also suitable for softened metals, surface heat treatment and chemical heat treatment, etc.
FEATURES AT A GLANCE
1.The body part of the product is formed by a casting process and has undergone a long-term aging treatment. Compared with the jigsaw technology, the long-term use of deformation is extremely small, and it can effectively adapt to various harsh environments;
2.Equipped with three test methods of Brinell, Rockwell and Vickers, with a seven-level test force, it can meet a variety of hardness test requirements;
3.The Rockwell hardness dial is directly read, and the Brinell and Vickers hardness are measured by the high-definition optical system;
4.The motor controls the loading, unloading, and load-holding process of the test force, which greatly reduces human operation errors;
5.Lever is added, no friction spindle, high precision of test force;
2.Equipped with three test methods of Brinell, Rockwell and Vickers, with a seven-level test force, it can meet a variety of hardness test requirements;
3.The Rockwell hardness dial is directly read, and the Brinell and Vickers hardness are measured by the high-definition optical system;
4.The motor controls the loading, unloading, and load-holding process of the test force, which greatly reduces human operation errors;
5.Lever is added, no friction spindle, high precision of test force;
PRODUCT SPECIFICATIONS
Initial test force | 98.07N（10kgf） Tolerance ±2.0% |
Tolerance of total test force | ±1.0% |
Test force | Brinell : 306.5N (31.25kg), 612.9N (62.5kg), 1839N (187.5kg) |
Rockwell: 588.4N (60kg), 980.7N (100kg), 1471N (150kg) | |
Vickers: 294.2N (30kg), 980.7N (100kg) | |
Indenter specifications | Diamond Rockwell indenter |
Diamond Vickers indenter | |
φ1.5875mm、φ2.5mm、φ5mm ball indenter | |
Delay control | 2～60 seconds adjustable |
Distance from the center of the indenter to the body | 165mm |
The maximum allowable height of the tested piece | Rockwell：170mm |
Brinell、Vickers：140mm | |
Magnification of microscope | 37.5X, 75X |
Dimensions | 520×240×700mm |
