ZG4020 heat Shrinking machine tray ZGCM
- Category: >>>
- Supplier: Henan Zgcm Machinery Co. ltd.
Share on (1600248091422):
Product Overview
Description
Technical specifications
MODEL | ZG4020C | ZG5030 | ZG6030 | ||
Voltage(V-Hz) | 380V50-60HZ | 380V/50-60HZ | 380V/50-60HZ | ||
Power(Kw) | 9KW | 11KW | 11KW | ||
Capacity(PCS/h) | 0-15m/min | 0-15m/min | 0-15m/min | ||
Tunnel Size(L*W*H)(mm) | 1200x400x200mm | 1200x500x300mm | 1200x600x300mm | ||
Product size(W*H)(mm) | 350 x 150mm | 450 x 250mm | 550 x 250mm | ||
Transport material | Mesh belt、Roller chain、Teflon | ||||
Conveying load | 20kg Max. | 20kg Max. | 20kg Max. | ||
External Dimens ions(L*W*H)(mm) | 1600x560x660mm | 1600x660x760mm | 1600x760x760mm | ||
weight | 80kg | 90kg | 100kg | ||
Applicable shrinkage film | PE, POF, PVC, PP | PE, POF, PVC, PP | PE, POF, PVC, PP | ||
Application products
Suitable for PVC, PP, POF PE and other types of shrink film
If you have special needs, you can contact us at any time. Customize your exclusive equipment
If you have special needs, you can contact us at any time. Customize your exclusive equipment
Machine advantage
Beautiful machine, stable quality, safety, energy saving, patented products, domestic initiative； applicable to the POF PVC PP film thermal shrink packaging effect is perfect. Features：
1 .Appearance and knot design in accordancewith national standards, the fuselage usesfingerprint resistant sheet production afterspray treatment.
2.Control panel using programming system, 12V DC input, button switch, digital display.
3.Transmission using 24V DC motor speed control using variable frequency technology 0-9 file adjustment.
4.The conveyor belt can be used wire mesh beltchain roller. Teflon mesh belt three.
5.Heating using 600W 220V far infrared quartzheating tube.
6.Temperature control using high precision intelligent temperature control system, up and down temperature independent regulation.
7.Hot air circulation using 220V 60W 2200 to the long axis motor with wind wheel.
8.The bracket can be disassembled, and the height of the bracket can be adjusted.
9.longer type packaging effect is more perfect, more efficient and energy saving.
1 .Appearance and knot design in accordancewith national standards, the fuselage usesfingerprint resistant sheet production afterspray treatment.
2.Control panel using programming system, 12V DC input, button switch, digital display.
3.Transmission using 24V DC motor speed control using variable frequency technology 0-9 file adjustment.
4.The conveyor belt can be used wire mesh beltchain roller. Teflon mesh belt three.
5.Heating using 600W 220V far infrared quartzheating tube.
6.Temperature control using high precision intelligent temperature control system, up and down temperature independent regulation.
7.Hot air circulation using 220V 60W 2200 to the long axis motor with wind wheel.
8.The bracket can be disassembled, and the height of the bracket can be adjusted.
9.longer type packaging effect is more perfect, more efficient and energy saving.
Shrinkage effect
Our workshop
Our factory
Henan ZGCM Machinery Co.,Ltd. has a plant area of more than 10,000 square meters, which produces vertical packaging machines, automatic material sorting lines, pillow packaging machines, filling machines, etc. Among them, granule packaging machine, powder packaging machine, liquid packaging machine, sauce packaging machine, food packaging machine, multi-head weighing machine, hardware packaging machine, counting packaging machine, medical supplies packaging machine, fresh fruit and vegetable packaging machine, filling machine, Capping series, unscramble bottle washing series, filling production line, etc. are the company's main products, which are exported to hundreds of countries and regions in Southeast Asia, Europe, America, Africa, the Middle East, etc., and are well received by users from all over the world! The company always adheres to the development strategy of "customer first, worry-free after-sales", pays attention to the reserve and training of talents, and has long-term exchanges of talents and technology with famous enterprises at home and abroad. The factory currently has more than 180 employees, including 35 in the R&D department, who are responsible for the R&D and design of non-standard equipment and advanced technology in the industry. The after-sales department has 30 masters with more than 20 years of after-sales experience, who are responsible for the installation of equipment sold at home and abroad. Commissioning, operation training and technical maintenance. We aim to realize enterprise packaging intelligence, liberate people from heavy packaging production, let machines replace manual work, reduce production costs, and improve production efficiency
Company history
Cooperation Case
Our client
transport
Frequently Asked Questions and Answers
1. Q: Do you have a finished machine to see?
Yes, we have standard machine inventory.
2. Q: Will you check before leaving the factory?
Yes it is. Every step of production and completion will be checked by QC department before shipment.
3. Q: Can overseas services be provided?
Yes, engineers can go abroad to train workers, install and debug machines for free
4. Q: How long is the warranty period?
One year machine warranty.
5. Q: What is the delivery time?
15-25 days after receiving the deposit.
Yes, we have standard machine inventory.
2. Q: Will you check before leaving the factory?
Yes it is. Every step of production and completion will be checked by QC department before shipment.
3. Q: Can overseas services be provided?
Yes, engineers can go abroad to train workers, install and debug machines for free
4. Q: How long is the warranty period?
One year machine warranty.
5. Q: What is the delivery time?
15-25 days after receiving the deposit.
