QC11Y QC11K 20 мм * 2500 мм E21S Металлическая стальная пластина гидравлический Гильотинный режущий станок для продажи (1600249323560)

Share on:


Price:18 733,00 $ - 20 815,00 $
Price in USD:Details

Quantity:


Product Overview

Description







Type
Cutting Thickness
Cutting Width
Cutting Angle
Bumper distance
Throat depth
Travel Times
Power
Dimension
(mm)
(mm)
(°)
(mm)
(mm)
(Min﹣¹)
(KW)
L×W×H(mm)
6×2500
6
2500
0.5°~1°30´
600
80
14
7.5
3100×1725×1960
6×3200
6
3200
0.5°~1°30´
600
80
12
7.5
3650×1750×1980
6×4000
6
4000
0.5°~1°30´
600
80
10
7.5
4650×1780×2075
6×5000
6
5000
0.5°~1°30´
600
80
8
7.5
5650×1830×2250
6×6000
6
6000
0.5°~1°30´
600
80
8
7.5
6650×1890×2380
8×2500
8
2500
0.5°~1°30´
600
80
14
7.5
3100×1725×1960
8×3200
8
3200
0.5°~1°30´
600
80
12
7.5
3850×1750×1980
8×4000
8
4000
0.5°~1°30´
600
80
10
7.5
4650×1850×2075
8×5000
8
5000
0.5°~2°
600
80
7
15
5805×2000×2500
8×6000
8
6000
0.5°~2°
600
100
7
15
6805×2115×2715
10×2500
10
2500
0.5°~2°30´
600
120
10
15
3195×1800×2210
10×3200
10
3200
0.5°~2°30´
600
120
8
15
3895×1800×2240
10×4000
10
4000
0.5°~2°30´
600
120
6
15
4695×1930×2275
10×5000
10
5000
0.5°~2°30´
600
120
5
15
5905×2115×2715
10×6000
10
6000
0.5°~2°30´
600
120
5
15
6905×2215×2800
12×2500
12
2500
0.5°~2°30´
600
120
10
15
3195×1800×2210
12×3200
12
3200
0.5°~2°30´
600
120
8
15
3895×1800×2240
12×4000
12
4000
0.5°~2°30´
600
120
6
15
4710×1950×2485
12×5000
12
5000
0.5°~2°30´
600
120
5
18.5
5905×2115×2800
12×6000
12
6000
0.5°~2°30´
600
120
4
18.5
7000×2300×3100
16×2500
16
2500
0.5°~2°30´
600
120
8
15
3215×1880×2340
16×3200
16
3200
0.5°~2°30´
600
120
7
15
3915×1880×2445
16×4000
16
4000
0.5°~2°30´
600
120
6
15
4715×1950×2590
16×5000
16
5000
0.5°~3°
600
120
5
22
6000×2300×3000
16×6000
16
6000
0.5°~3°
600
120
4
37
7000×2300×3100
20×2500
20
2500
0.5°~3°
600
120
6
22
3215×1890×2465
20×3200
20
3200
0.5°~3°
600
120
5
30
4120×1890×2780
20×4000
20
4000
0.5°~3°
600
120
4
30
4925×2150×2900
20×5000
20
5000
0.5°~3°
600
120
4
37
6000×2300×3050
25×2500
25
2500
0.5°~3.5°
600
120
5
30
3435×2000×2710
25×3200
25
3200
0.5°~3.5°
600
120
5
30
4120×2200×3000
25×4000
25
4000
0.5°~3.5°
600
120
3
30
4950×2200×3150
30×2500
30
2500
1°~3.5°
600
120
4
30
3435×2020×2770
30×3200
30
3200
1°~3.5°
600
120
3
37
4200×2300×3200






1.Hydraulic plate shears of second generation;
2.Total steel welded structure,internal stress eliminated by heat treatment and excellent rigidness and stability;
3.Advanced integral hydraulic system with good reliability;
4.Three-point contact bearing guideway that can eliminate the bearing clearance so as to improve the shearing quality;
5.Rapid,convenient and accurate hand-wheel adjustment of blade clearance;
6.Rectangular blade with four edges usable and with long service life;
7.Adjustable shearing angle to reduce the distortion and deformation of the plate;
8.Inward incline structure for the upper blade holder for an easy blanking and workpiece accuracy improvement;
9.Rolling the ball,reducing sheet scratches and reducing frictional resistance;
10.Electric rear block,digital display,convenient and accurate;
11.Back support device(optional)




















Q1: After I buy the machine, what will you do if I don't know some of the function?
A1: We will show you how to use the machine perfectly. Technical support and the video is available.

Q2: Will you show me how to install the machine?
A2: Certainly, we will enclose the production specification with the machine, and we could provide the video online to you, and our engineers are available to service machinery overseas.

Q3: How about your after sales service?
A3: Our experienced engineers are waiting to make service for you. One-top service term made us survive from fierce competition.

Q4: What's the policy for guarantee and broken parts?
A4: Warranty period of equipment lasts two years, during which the broken parts and spares caused by quality can be offered free.
