HP TF T Customized Biodegradable Plastic Japanese Garbage Bag Three Times Folding T shirt Plastic Bag Making Machine
- Category: Packaging Material Making Machines >>>
- Supplier: Suzhou,Hanplas,Machinery,Co.,Ltd.
Share on:
Product Overview
Description
Specification
Model | HP-TF900 |
Max.bag width (mm) | 900 |
Max.bag length (mm) | 1200 |
Max speed (pcs/min) | 80 |
Max sealing thickness (mm/layer) | 0.01-0.1 |
Air Volume (kg/cm2) | 7 |
Power Required (Kw) | 14 |
Available material | PP, PE |
Weight (kg) | 2380kg |
Dimension (mm) | 5800*1650*1800 |
Applications
Flat garbage bags with 3 folds.
Flat garbage bags with 3 folds.
Parts
* .The overall struction adopt steel plate :10mm thickness
* .Feeding motor adopt servo motor: Mitsubishi brand, Japan
* .Coopersealer: single line sealer ,silicone below sealing knife
* .Controller:1 set,PLC, Japan brand; Touch screen :Weinview, Taiwan brand
* .One photoelectric for printing bag,SICK brand ,Made in Germany
* .The machine color :white&green, anti-static painting
* .Main motor,5KW AC motor with reducer
* .Transmission bearing adopt NSK brand,Japan
*.Cutting knife, Taiwan brand
* .The overall struction adopt steel plate :10mm thickness
* .Feeding motor adopt servo motor: Mitsubishi brand, Japan
* .Coopersealer: single line sealer ,silicone below sealing knife
* .Controller:1 set,PLC, Japan brand; Touch screen :Weinview, Taiwan brand
* .One photoelectric for printing bag,SICK brand ,Made in Germany
* .The machine color :white&green, anti-static painting
* .Main motor,5KW AC motor with reducer
* .Transmission bearing adopt NSK brand,Japan
*.Cutting knife, Taiwan brand
Features
*. Auto lifting design of high pressure air cylinder
*. Unwinding adopts magnetic powder tension
*. Photoelectric printing tracking control for accurate registration
*. Feed wheel and pull device controlled by servo motor
*. Computer control full automatically, touch screen and human-machine interface, easy for correction and fine adjustment
*. Auto lifting design of high pressure air cylinder
*. Unwinding adopts magnetic powder tension
*. Photoelectric printing tracking control for accurate registration
*. Feed wheel and pull device controlled by servo motor
*. Computer control full automatically, touch screen and human-machine interface, easy for correction and fine adjustment
