Laboratory furniture LAB scientific customized fume hood
- Category: >>>
- Supplier: Galf (wuxi) Imp. & Exp. Co. Ltd.
Share on (1600250368804):
Product Overview
Description
Product Description
Specification
Technical parameters
Model | GFH1000 | GFH1200 | GFH1500 | GFH1800 | |||
External Size (W*D*H) | 1040*750*2200mm | 1240*800*2200mm | 1540*800*2200mm | 1840*800*2200 mm | |||
Internal Size (W*D*H) | 820*520*872mm | 1020*570*872mm | 1320*570*872mm | 1620*570*872 mm | |||
Work Surface Height | 700mm | ||||||
Max Opening | 815mm | ||||||
Air Velocity | 0.4~0.6m/s | ||||||
Noise | ≤60dB | ||||||
Fluorescent Lamp | 12W*1 | 30W*2 | 30W*2 | 30W*2 | |||
Blower | Built-in axial flow blower; Speed adjustable. | ||||||
Front Window | Manual, 5mm toughened glass, height adjustable . | ||||||
Power Supply | AC220V±10%, 50/60Hz ; 110V±10%, 60Hz | ||||||||
Consumption | 330W | 360W | 360W | 360W | |||||
Material | Main Body | Made of Porcelain white PP, thickness 8mm, resistant to strong acid, alkali and anti-corrosion | |||||||
Work Table | Chemical resistant phenol resin | ||||||||
Standard Accessory | Fluorescent lamp, Water tap, Gas tap, Water Sink, Base cabinet | ||||||||
Waterproof socket*2 | |||||||||
4 meter PVC duct, Diameter:250mm | |||||||||
Optional Accessory | PP work table, epoxy resin board or ceramic board. | ||||||||
Outer centrifugal blower, resistant to strong acid, alkali. | |||||||||
Gross Weight | 160kg | 198kg | 225kg | 259kg | |||||
Package Size | Main Body | 1110*835*1575 mm | 1310*885*1575 mm | 1610*885*1575 mm | 1910*885*1575 mm | ||||
(W*D*H) | Base Cabinet | 1110*790*950 mm | 1310*840*950 mm | 1610*840*950 mm | 1910*840*950 mm | ||||
Fume Hood Introduction
Fume hood is a very important part of ventilation system in laboratory. Laboratory should have a good ventilation environment to keep experimenters away from inhaling or swallowing hazardous gases, smoke, dust, mist and particulate matters or organisms etc. Fume hood is designed for removing these hazardous matters from laboratory.
Standard Characters of PP Fume Hood
1.Shell: made of 8mm white PP board which has excellent anti-corrosion performance, with seamless welding make sure a strong compact structure and tightness.
2.Cabinet door: made of 8mm white PP board, with shutter for ventilation inside the cabinet.
3.Worktop: made of 10mm white PP board, double-layer water-collecting structure. Epoxy resin or phenolic resin or ceramic worktop are optional.
4.Air collection hood: cone shape collecting hood made of white PP board.
5.Fluorescent lamp: fully cover fluorescent lamp, model 1200/1500 is 30W, model 1800 is 40W.
6.Handle: PP handle
7.Hinge: PP hinge
8.Touch control panel: with buttons of power, fan, volume switch, lighting etc.
9.Air deflector: 8mm imported white PP board with excellent anti-corrosion performance.
10.Power: 4 PCS AC 220V, 10A sockets, 1 main power switch and 1 backup power switch.
11.Viewing window: 5mm transparent PVC board
12.Assay sink: one-piece form PP sink, acid and alkali resistant, with filtering and stink-block function.
13.Water tap: 1 pc single outlet water tap.
14.Air tap: air tap is optional.
note:
1. The above dimensions are standard dimensions.
2. Custom size can be provided.
3. The price of the ventilation system is not included. The size of the induced draft fan and the pipe depends on the laboratory layout on site.
1. The above dimensions are standard dimensions.
2. Custom size can be provided.
3. The price of the ventilation system is not included. The size of the induced draft fan and the pipe depends on the laboratory layout on site.
