Заводская оптовая продажа, прочный глушитель выхлопной трубы для адсорбционной сушилки хорошего качества
- Category: Pneumatic Parts >>>
- Supplier: Wuxi Hualing Filter Equipment Co. Ltd.
Share on (1600250585731):
Product Overview
Description
Specification
Model No. | Connection size |
GXY-02 | 1/4” |
GXY-05 | 1/2" |
GXY-07 | 3/4" |
GXY-10 | 1" |
GXY-12 | 1-1/4” |
GXY-15 | 1-1/2" |
GXY-20 | 2" |
GXY-30 | 3" |
Product Description
Technical specification:
a. Application: exhaust muffler for adsorption dryer
b. Function: noise reduction
c. Model Number: GXY-02, GXY-05, GXY-07, GXY-10,G XY-12, GXY-15, GXY-20, GXY-30
d. Flow rate: 1.42~ 51 Nm3/min.
e. Connection size: 1/4”, 1/2”, 3/4”, 1”, 1-1/4”, 1-1/2”, 2”, 3”
f. Thread type: BSPT, NPT
g. Noise reduction: 30db and above
h. Material outside: galvanized plate, stainless steel screen
i. Filter media: sound-absorbing ultrafine glass wool
j. Operating temperature: ≤65℃
k. Max. operating pressure: 10bar
l. Opening pressure of bypass safety valve: 2.0~2.2 kgf/cm2
a. Application: exhaust muffler for adsorption dryer
b. Function: noise reduction
c. Model Number: GXY-02, GXY-05, GXY-07, GXY-10,G XY-12, GXY-15, GXY-20, GXY-30
d. Flow rate: 1.42~ 51 Nm3/min.
e. Connection size: 1/4”, 1/2”, 3/4”, 1”, 1-1/4”, 1-1/2”, 2”, 3”
f. Thread type: BSPT, NPT
g. Noise reduction: 30db and above
h. Material outside: galvanized plate, stainless steel screen
i. Filter media: sound-absorbing ultrafine glass wool
j. Operating temperature: ≤65℃
k. Max. operating pressure: 10bar
l. Opening pressure of bypass safety valve: 2.0~2.2 kgf/cm2
Company Profile
Wuxi Hualing Filter Equipment Co., Ltd, founded in 1992, specializes in manufacturing high-efficient precision filters for compressed air, filter elements, air oil separators for vacuum pump, lubrication station of centrifugal compressor and mechanical machining.
The company is one of the drafters for national standard GB/T 30475.1 & GB/T 30475.2, and possesses the most advanced test stand, imported from German GMN Company, which is in accordance with ISO 8573-2 and ISO 12500-1 standard, to guarantee the product quality.
It mainly supplies the filter products for such industries as machinery, textile, chemical, electronic, transportation, aviation and environmental protection etc. The products export to Europe and America, Asia, South Africa, accounting for around 30% of the overall business.
With good credit and rich practical experiences, the company provides you with advanced manufacturing and testing methods, high-quality products, reasonable prices and efficient service.
The company is one of the drafters for national standard GB/T 30475.1 & GB/T 30475.2, and possesses the most advanced test stand, imported from German GMN Company, which is in accordance with ISO 8573-2 and ISO 12500-1 standard, to guarantee the product quality.
It mainly supplies the filter products for such industries as machinery, textile, chemical, electronic, transportation, aviation and environmental protection etc. The products export to Europe and America, Asia, South Africa, accounting for around 30% of the overall business.
With good credit and rich practical experiences, the company provides you with advanced manufacturing and testing methods, high-quality products, reasonable prices and efficient service.
Our Advantages
Exhibition
Customer Photos
Packing & Delivery
Why Choose Us
a. 25 years’ practical experiences in design, development and manufacturing;
b. Strong technical force and advanced testing method;
c. Complete and perfect process documents and production lines;
d. Reliable and durable products with affordable prices;
e. High-quality and efficient service;
f. Sufficient inventory and timely delivery
b. Strong technical force and advanced testing method;
c. Complete and perfect process documents and production lines;
d. Reliable and durable products with affordable prices;
e. High-quality and efficient service;
f. Sufficient inventory and timely delivery
Our service
a. Providing professional consultation, technical support and special solutions
b. Providing timely feedback on complaints
c. Providing perfect after sales service and warranty
b. Providing timely feedback on complaints
c. Providing perfect after sales service and warranty
FAQ
Q1. What kind of your company is it?
We’re the manufacturer integrated with R&D, production and sales.
Q2. How about your technical conditions and production capability?
Q3. What is the delivery time?
Q4. Do you have a warranty?
Q5. Can you supply customized product?
Q2. How about your technical conditions and production capability?
Complete process documents and equipments, mass production.
Q3. What is the delivery time?
Delivery time depends on the order quantity, normally is 1-30 working days after 100% payment.
Q4. Do you have a warranty?
Yes, for filters, it is 1 year and for elements, it is 8000 hours at least.
Q5. Can you supply customized product?
Yes, we have a professional technical team to provide you with the best solution and complete production processes and control to provide you with satisfied product.
