Rotary vacuum aquaculture pond fish farming koi drum filter for spirulina
- Category: >>>
- Supplier: Shandong Kangtailong Intelligent Equipment Co. Ltd.
Share on (1600255337238):
Product Overview
Description
Products Description
Microfiltration machine
The microfilter is a kind of screen filter which can intercept fine suspended matters. It has a drum shaped metal frame. The drum rotates around the horizontal axis, and there is a support net and working net woven by stainless steel wire (also copper wire or chemical fiber) on it. It can be used to filter the raw water of waterworks and remove plankton such as algae and water fleas. It can also be used to filter the industrial water, recover the swimming substance in the industrial wastewater and finally treat the sewage.
The microfilter is a purification device which uses 80-200 mesh / square inch microporous screen fixed on the drum type filtration equipment to achieve solid-liquid separation by intercepting the solid particles in the aquaculture water body. At the same time of filtration, the microporous screen can be cleaned in time by the rotation of the drum and the force of backflushing water. Keep the equipment in good working condition at all times. The microfilter of our company is aimed at the problems of existing microfilter, such as easy blockage, easy damage, easy corrosion, difficult maintenance, etc. it is one of the * application technologies applicable to the treatment of seawater circulating aquaculture water. Through the separation of solid waste in aquaculture water, the product can purify the water and achieve the purpose of recycling.
2 product application:
In the field of aquaculture, microfilter is more used in the first stage filtration of raw water to remove large particles of sediment, suspended algae, particles, etc. Or it can be used in the first stage of the closed cycle purification.
3 product advantages:
1. The head loss of the equipment is small, energy saving and high efficiency.
2. Compact structure and small floor area
3. Automatic back washing device, stable operation and convenient management.
4. Micro filter for seawater factory culture.
5. Application of 316L stainless steel and * corrosion-resistant materials to enhance seawater corrosion resistance.
The microfilter is a purification device which uses 80-200 mesh / square inch microporous screen fixed on the drum type filtration equipment to achieve solid-liquid separation by intercepting the solid particles in the aquaculture water body. At the same time of filtration, the microporous screen can be cleaned in time by the rotation of the drum and the force of backflushing water. Keep the equipment in good working condition at all times. The microfilter of our company is aimed at the problems of existing microfilter, such as easy blockage, easy damage, easy corrosion, difficult maintenance, etc. it is one of the * application technologies applicable to the treatment of seawater circulating aquaculture water. Through the separation of solid waste in aquaculture water, the product can purify the water and achieve the purpose of recycling.
2 product application:
In the field of aquaculture, microfilter is more used in the first stage filtration of raw water to remove large particles of sediment, suspended algae, particles, etc. Or it can be used in the first stage of the closed cycle purification.
3 product advantages:
1. The head loss of the equipment is small, energy saving and high efficiency.
2. Compact structure and small floor area
3. Automatic back washing device, stable operation and convenient management.
4. Micro filter for seawater factory culture.
5. Application of 316L stainless steel and * corrosion-resistant materials to enhance seawater corrosion resistance.
Images
Product Paramenters
Model | WL-1 | WL-2 | WL-3 | WL-4 |
Filter area | 5m2 | 7m2 | 9m2 | 11m2 |
Filtering mesh | 60-225 | 60-250 | 60-250 | 60-250 |
Filtration capacity | 50-100t/h | 80-150t/h | 100-200t/h | 120-240t/h |
Drum speed | 4-6r/min | 4-6r/min | 4-6r/min | 4-6r/min |
Flushing water pressure | 0.3mpa | 0.3mpa | 0.3mpa | 0.3mpa |
Motor power | 1.1k | 1.5kw | 1.5kw | 2.2kw |
roller diameter | 1000mm | 1250mm | 1250mm | 1500mm |
Company Profile
Shandong kangtailong Intelligent Equipment Co., Ltd. is a design and manufacturing enterprise of various chemical rubber equipment, sewage treatment equipment, waste gas treatment equipment, food machinery equipment, solid waste treatment of domestic garbage (harmless treatment of animal carcasses), various environmental protection heating equipment, wood anti-corrosion equipment. With a registered capital of 5 million yuan, the company has complete qualifications, advanced equipment, strong technical force, complete testing means and a sound and stable quality assurance system. It is committed to the R & D and design of rubber vulcanization equipment, sewage and waste gas equipment, heating and heating equipment. Is a set of design, manufacturing, installation as one of the modern new enterprises.
Our Advantages
1. Customized design according to the specific working conditions. To be the optimal structure design.2. Quick delivery time
andone-stop service for convenience and time saving.
3. After-sales service, video guidance, engineers can be door-to-door service.
4.Guarantee the service life of the equipment for 20 years.
andone-stop service for convenience and time saving.
3. After-sales service, video guidance, engineers can be door-to-door service.
4.Guarantee the service life of the equipment for 20 years.
Customer Photos
FAQ
Q: Are you manufacturer or trading company?
A:We are a professional manufacturer and exporter with 20 years of production experience.
Q: Where is your factory located? How can I visit there?
A：Our factory is located in Zhucheng, Shandong Province. You are warmly welcome at any time.
Q: How do you control the quality?
A: We insist that “Quality First, Customer First”, and always pay attention to quality control from the beginning to the end. One year warranty period, ISO9001:2008, CE, Certificates.
Q: How to pay?
A: T/T, L/C, Western Union, Money Gram,Credit Card are available.
Q: How long is the delivery time?
A: About 10-40 days upon the payment date.
