Product Overview
Description
Product Overview
SIP2101T
SIP2101T network audio module is a universal independent SIP audio function module, which can be easily embedded in OEM products.
This module encodes and decodes the SIP protocol and RTP audio stream from the network.The module supports a variety of network protocols and audio codec protocols, and can be used for applications such as VoIP and IP paging, and high-quality music streaming media playback.
This module encodes and decodes the SIP protocol and RTP audio stream from the network.The module supports a variety of network protocols and audio codec protocols, and can be used for applications such as VoIP and IP paging, and high-quality music streaming media playback.
FEATURES AT A GLANCE
Network alarm, network player
* Universal two-way full-duplex VoIP intercom for paging and internal communication applications
* Source encoder for IP audio distribution applications
* Background music and music hold encoder for VoIP applications
* Suitable for various low-latency IP audio encoders
* Universal two-way full-duplex VoIP intercom for paging and internal communication applications
* Source encoder for IP audio distribution applications
* Background music and music hold encoder for VoIP applications
* Suitable for various low-latency IP audio encoders
SIP2103T
SIP2401T
SIP2701T
PRODUCT SPECIFICATIONS
Power input | DC 4.7 ~ 16 V.Maximum working current, 200mA |
Temperature | Industrial grade: - 40 ~ 65 ℃.Storage temperature range - 40 ~ 85 ℃ |
Network interface | 10 / 100M base adaptive Ethernet interface,IPv4 capable.SIP,TCP/IP, UDP, RTP,DHCP,HTTP |
Mic / linein input | Typical amplitude 1000mvrms Frequency response: 20 Hz … 20 kHz (-3 dB) Dynamic range: 90 dB, SNR -90 dB, THD <0.05% |
Line out output | load 510 Ω, typical 1000vrms, SNR 95dB (in playback mode) |
Bidirectional mode （Intercom mode） | AEC(Linear and non-linear )8kHz sampling, ADPCM coding. The minimum delay is 80 ms |
Decoding mode （playback mode） | Wav (PCM + ima ADPCM),Mp3 ,G.711 a/u, G.722 and other formats. (Provide stereo playback, maximum 48Khz, 320kbps audio stream The minimum delay is 50ms) |
Encoding mode （recording mode） | G.711a/u, G.722 The minimum delay is 30ms |
Control serial interface | Baud rate 115.2kbps |
Module size | Length × width × height: 50 × 50 × 17mm |
