IPC HDW3641TM AS 6MP built in Mic IR Fixed focal Eyeball WizSense Waterproof Mini Dome Network Camera
- Category: >>>
- Supplier: Shenzhen Lin Wei Ke Xun Technology Co. Ltd.
Share on (1600263248243):
Product Overview
Description
Recommend Products
Products Description
IPC-HDW3841EM-AS 8MP 4K built-in Mic IR Fixed focal Eyeball WizSense Waterproof Mini Dome Network Camera
6MP,1/2.7”progressive scan CMOS, low illuminance, high image
definition
* Outputs max. 6MP (3072 × 1728) @20 fps,and supports
4MP(2688 x 1520)@30fps
* H. codec, high compression rate, low bit rate
* Built-in IR LED, max. IR distance: 50 m
* ROI, SMART H.264+/H.+, flexible coding, applicable to various
bandwidth and storage environments
* Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, ap
plicable to various monitoring scenes
* Intelligent detection: Tripwire, intrusion
* Abnormality detection: Motion detection, video tampering, defocus
detection; scene changing, audio detection, no SD card, SD card full,
SD card error, network disconnection, IP conflict, illegal access, voltage
detection
* Supports max. 256 G Micro SD card, built-in Mic
* 12V DC/PoE power supply
* IP67 protection
* SMD Plus
definition
* Outputs max. 6MP (3072 × 1728) @20 fps,and supports
4MP(2688 x 1520)@30fps
* H. codec, high compression rate, low bit rate
* Built-in IR LED, max. IR distance: 50 m
* ROI, SMART H.264+/H.+, flexible coding, applicable to various
bandwidth and storage environments
* Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, ap
plicable to various monitoring scenes
* Intelligent detection: Tripwire, intrusion
* Abnormality detection: Motion detection, video tampering, defocus
detection; scene changing, audio detection, no SD card, SD card full,
SD card error, network disconnection, IP conflict, illegal access, voltage
detection
* Supports max. 256 G Micro SD card, built-in Mic
* 12V DC/PoE power supply
* IP67 protection
* SMD Plus
Camera | IPC-HDW3641TM-AS 6MP built-in Mic IR Fixed focal Eyeball WizSense Waterproof Mini Dome Network Camera |
Image Sensor | 1/2.7” 6Megapixel progressive scan CMOS |
Max. Resolution | 3072(H) x 1728(V) |
ROM | 128 MB |
RAM | 512 MB |
Scanning System | Progressive |
Electronic Shutter Speed | Auto/Manual, 1/3 s–1/100000 s |
Min. Illumination | 0.005 Lux @F1.6 |
S/N Ratio | ＞56 dB |
Illumination Distance | 50 m (164.0 ft) |
Illuminator On/Off Control | Auto/Manual |
Illuminator Number | 2 (IR LED) |
Pan/Tilt/Rotation Range | Pan: 0˚–360˚; Tilt: 0˚–78˚; Rotation: 0˚–360˚ |
Lens | |
Lens Type | Fixed-focal |
Mount Type | M12 |
Focal Length | 2.8 mm; 3.6 mm |
Max. Aperture | F1.6 |
Field of View | 2.8 mm: Horizontal 99° × Vertical 53° × Diagonal 115° 3.6 mm: Horizontal 80° × Vertical 43° × Diagonal 94° |
Iris Type | Auto |
Close Focus Distance | 2.8 mm: 0.9 m (3.0 ft) 3.6 mm: 1.6 m (5.3 ft) |
DORI Distance | Lens |
2.8 mm | |
3.6 mm | |
Professional, intelligent | |
IVS (Perimeter Protection) | Tripwire; intrusion (Recognition of human and vehicle) |
Intelligent Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. |
Video | |
Video Compression | H.,H.264,H.264B,H.264H,MJPEG (only supported by sub stream) |
Smart Codec | Smart H.+/ Smart H.264+ |
Video Frame Rate | Main stream (3072 × 1728@1–20 fps/ 2688 × 1520@1–25/30 fps) Sub stream (704 × 576@1–25 fps/ 704 × 480@1–30 fps) Third stream (1920 × 1080@1–25/30 fps) |
Stream Capability | 3 streams |
Resolution | 3072 × 1728; 2592 × 1944; 2688 × 1520; 2560 × 1440; 2304 ×1296; 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (354 × 288/354 × 240) |
Bit Rate Control | CBR/VBR |
Video Bit Rate | H.264: 32 Kbps–8192 Kbps, H.: 19 Kbps–8192 Kbps |
Day/Night | Auto (ICR)/Color/B/W |
BLC | Yes |
HLC | Yes |
WDR | 120 dB |
Scene Self-adaptation | Yes |
White Balance | Auto/natural/street lamp/outdoor/manual/regional custom |
Gain Control | Auto/Manual |
Noise Reduction | 3D DNR |
Motion Detection | OFF/ON (4 areas, rectangular) |
Region of Interest (RoI) | Yes (4 areas) |
Smart Illumination | Yes |
Defog | Yes |
Image Rotation | 0°/90°/180°/270° (Support with 1080p resolution and lower) |
Mirror | Yes |
Privacy Masking | 4 areas |
Built-in MIC | Yes |
Audio Compression | G.711a; G.711Mu; G.726; AAC; G.723 |
Alarm Event | No SD card; SD card full; SD card error; less service time of SD card (smart card supports); network disconnection; IP conflict; illegal access; voltage detection; security exception; motion detection; video tampering; scene changing; intensity change; tripwire; intrusion; SMD |
Network | RJ-45 (10/100 Base-T) |
SDK and API | Yes |
Protocol | IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; SNMP |
Interoperability | ON-VIF (Profile S/Profile G/Profile T), CGI, Milstone, Genetec, P2P |
User/Host | 20 Users |
Storage | FTP; SFTP; Micro SD Card (support max. 256 G); Dahua Cloud; NAS |
Browser | IE: IE8 and later Chrome Firefox |
Management Software | Smart PSS, DSS, DMSS |
Mobile Phone | IOS; Android |
Certification | |
Certification | EN 55032 EN 61000-3-2 EN 61000-3-3 EN 55024 EN 50130-4 EN55035 |
Power | |
Power Supply | 12V DC (±30%), PoE (802.3af) |
Power Consumption | <7.2W |
Environment | |
Operating Conditions | -40°C to +60°C (-40°F to +140°F)/less than 95% |
Storage Conditions | -40° C to +60° C (-40° F to +140° F) |
Protection Grade | IP67 |
Structure | |
Casing | Metal |
Dimensions | Φ106 mm × 93.6 mm (4.17” × 3.69”) |
Net Weight | 0.55 kg (1.21 lb) |
Gross Weight | 0.71 kg (1.57 lb) |
Browser | IE: IE8; IE9; IE11 |
Chrome | |
Firefox | |
Management Software | Smart PSS; DSS; DMSS |
Mobile Phone | IOS; Android |
Certification | |
Certifications | CE-LVD: EN62368-1 |
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU | |
FCC: 47 CFR FCC Part 15, Subpart B | |
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 | |
Power | |
Power Supply | 12V DC/PoE (802.3af) |
Power Consumption | Basic power consumption: 2.6W (12V DC); 3.3W (PoE) |
Max. power consumption (WDR + H. + IR LED intensity): 6.9W (12V DC); 7.9W (PoE) | |
Environment | |
Operating Conditions | –40°C to +60°C (–40°F to +140°F)/Less than 95% RH |
Storage Conditions | –40°C to +60°C (–40°F to +140°F) |
Protection Grade | IP67 |
Structure | |
Casing | Metal |
Dimensions | 93.6 mm × Φ106 mm (3.7" × Φ4.2") |
Net Weight | 530 g (1.1 lb) |
Gross Weight | 800 g (1.7 lb) |
