Germany DURBAL Rod End Bearing BRTM40-30-501 BRTM 40-30-501:
Product Details
Premium Line Rod Ends low maintenance, lubrication possible rod ends with integral self-aligning roller or ball bearing.
Male thread greasable, low maintenance, shields adapter.
Rod end housing: forged steel, tempered,case hardened,bearing race,ground and lapped,rolled thread, surface galvanized
Inner ring: ball bearing steel, hardened, superfine ground
Lubrication: Polyrex EP2 or soap complex
temperature range -20 °C to +120 °C
Bearing clearance: 15 - 30 μm radial
Specifications
| Name: | Rod end bearing |
| Connection Size | M16 x 2 Male |
| Bore Size | 16mm |
| Dynamic Load Rating | 13.3kN |
| Static Load Rating | 8.9kN |
| Overall Length | 87mm |
| Material | Forged Steel |
| Connection Thread Standard | Metric |
| Maximum Operating Temperature | +120°C |
| Minimum Operating Temperature | -20°C |
| Connection Gender | Male |
DURBAL Rod end ball joint bearing:
| Type | d (mm) | G | d2 (mm) | l2 (mm) | |
|---|---|---|---|---|---|
| BRTM 10 - 00 - 501 | 10 | M 10 | 28 | 62 | |
| BRTM 10 - 00 - 502 | 10 | M 10 | 28 | 62 | |
| BRTM 12 - 00 - 501 | 12 | M 12 | 32 | 70 | |
| BRTM 12 - 00 - 502 | 12 | M 12 | 32 | 70 | |
| BRTM 16 - 00 - 501 | 16 | M 16 | 42 | 87 | |
| BRTM 16 - 00 - 502 | 16 | M 16 | 42 | 87 | |
| BRTM 20 - 00 - 501 | 20 | M 20 X 1,5 | 50 | 103 | |
| BRTM 20 - 00 - 502 | 20 | M 20 X 1,5 | 50 | 103 | |
| BRTM 25 - 00 - 501 | 25 | M 24 x 2 | 64 | 126 | |
| BRTM 25 - 00 - 502 | 25 | M 24 x 2 | 64 | 126 | |
| BRTM 30 - 00 - 501 | 30 | M 30 x 2 | 70 | 145 | |
| BRTM 30 - 00 - 502 | 30 | M 30 x 2 | 70 | 145 | |
| BRTM 35 - 00 - 501 | 35 | M 36 x 3 | 92 | 183 | |
| BRTM 35 - 00 - 502 | 35 | M 36 x 3 | 92 | 183 | |
| BRTM 40 - 00 - 501 | 40 | M 42 x 3 | 120 | 230 | |
| BRTM 40 - 00 - 502 | 40 | M 42 x 3 | 120 | 230 |
