Semi Automatic Pasteurizing Line Vacuum Packaging Food Tunnel Pasteurizer processing plant

Share on:

Price:RUB 2,677,857.00 - RUB 6,120,816.00
Price in USD:Details


Product Overview


Fully Automatic Beer Pasteurization Machine Tunnel Pasteurizer Company
Brief Introduction of Equipment
The spray pasteurizer is divided into four sections: 2m preheating, 4m sterilization, 2m pre-cooling, 2m cooling The spray
pasteurizer is composed of two parts, a sterilization section and a cooling section, with a short interval of one meter. It is
used for bottle capping. The purpose of the secondary capping is to allow the product to reach the vacuum after cooling to ensure the product’s quality. quality. The operation mode of the equipment adopts chain plate transmission and roller transmission, which improves the stability of product conveying. The running speed of the whole machine is adjustable, and the temperature is adjustable, which is suitable for the process requirements of different products and meets the diverse product processes of customers. The sterilization section of the spray pasteurizer is divided into two sections, each section is equipped with 2 circulating water pumps, one section is the preheat section, the water temperature is controlled at about 60 degrees, and its main function is to prevent glass bottles from breaking. The second stage is the sterilization stage, and the high temperature can reach 95 degrees. According to the different products, the sterilization temperature can be adjusted. The cooling section is divided into pre-cooling and cooling sections, the pre-cooling temperature is controlled at about 60 degrees, and the cooling section is cooled by water at room temperature. Each section of the spray pasteurizer is equipped with a circulating water tank,which saves energy and achieves the effect of water recycling while ensuring uniform heating temperature. The whole structure of the equipment adopts frame welding, and the material is made of stainless steel 304, which meets the food hygiene standards. The spray pasteurizer is an assembly line type, which effectively saves labor and improves productivity. This equipment is very popular among small and medium-sized enterprises. The spray pasteurization machine is a new product that our company absorbs foreign advanced technology and integrates the production technology of domestic food, beverage, pharmaceutical and other industries. It needs to successfully develop a new product that integrates sterilization, cooling and integration. The spray pasteurizer can be connected to the bottle washing machine, the air drying line, and directly label the label, which reduces labor and improves work efficiency.
spray bus sterilizer
Effective width of mesh belt
800 mm
Power supply
Running speed
frequency conversion speed regulation
Work rate
1.1 kw
Material quality
SUS304 stainless steel
Mesh belt running speed
frequency conversion
Temperature control
automatic temperature control
FL205 bearing, 304 material
Frame body
50*50*1.5 square tube, 304 material
Tank body
2mm thick, 304 stainless steel plate
M16 plastic cushion foot
1mm thick 304 stainless steel plate
Insulation plate
0.8mm thick 304 stainless steel plate
Inner baffle
1mm thick 304 stainless steel plate
Packing & Delivery
Company Profile
Customer Photos
1. who are we?
We are based in Liaoning, China, start from 2017,sell to Eastern Europe(10.00%),North America(8.00%),South America(7.00%),Southeast Asia(6.00%),Western Europe(5.00%),Eastern Asia(5.00%),Northern Europe(5.00%),Southern Europe(4.00%),Africa(3.00%),South Asia(2.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Pharmaceutical Machinery,Food Machinery,Packaging Machinery,Filling machinery,textile

4. why should you buy from us not from other suppliers?
Our company have built a long-term and stable cooperation relationship with many strong manufacturing enterprises in China,can supply the whole project service for our customers with high quality equipment,competitive price,reliable superior service.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF;
Accepted Payment Currency:USD;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese
