hi speed searoyal 63' yacht
US $37000-$39000
7.5m 25ft offshore aluminium walk around speed boat yacht center cabin fishing boat for sale
- Category: Yachts >>>
- Supplier: Shandong,Taixin,Ship,Manufacture,Co.,Ltd.
Share on:
Product Overview
Description
Product Description
The boat has beautiful streamline appearance,modern style color match.It is exllent boat for diving,sightseeing.
Length | 7.5m/25ft |
Beam | 2.45m |
Depth | 1.55m |
Number of people | 6-10 |
Engine Power | 200-300HP |
Warranty | 3 years |
Length of the hull(m) | 6.25m | 6.85m | 7.5m | 9m |
Beam (m) | 2.4m | 2.45m | 2.45m | 2.45m |
Depth(m) | 1.45m | 1.45m | 1.45m | 1.45m |
Bottomsides(mm) | 5mm | 6mm | 6mm | 6mm |
Topsides(mm) | 4mm | 5mm | 5mm | 5mm |
Transom (mm) | 5mm | 6mm | 6mm | 6mm |
Transom shaft | 25” | 25” | 25” | 25” |
weight(boat only kg) | 1290kg | 1450kg | 1670kg | 1950kg |
Min. HP | 150hp | 175hp | 200hp | 300hp |
MAX. HP | 225hp | 275hp | 300hp | 500hp |
Number of people | 6 | 7 | 8 | 9 |
Warranty : | 3 years | 3 years | 3 years | 3 years |
Manufacturing Technology
1.All of our fishing & working boat are made of Marine-grade aluminum 5083-h116 with China Ship Classification society ( CCS )
2.Welding Specification :
1) TIG and MIG are to be adopted for this ship .
2) The ultrasonic inspection to be carried out for the cross joint of seam and other important place .
3) From 5083-H116 material to welding wires to welding use gas & experienced qualified welders .
4) The bottom is double bottom system and constructed on the longitudinal system of framing .
5) Solid floors will be provided at every frame station , the side transverse frames will be fitted at a space of 500mm ."
1) TIG and MIG are to be adopted for this ship .
2) The ultrasonic inspection to be carried out for the cross joint of seam and other important place .
3) From 5083-H116 material to welding wires to welding use gas & experienced qualified welders .
4) The bottom is double bottom system and constructed on the longitudinal system of framing .
5) Solid floors will be provided at every frame station , the side transverse frames will be fitted at a space of 500mm ."
3.The Core Features Of Our safe Design
1) The Whole hull structure Manual bilge pump system
2) The underfloor fuel tank with cutoff valves and fuel inspection hose with heavy duty fuel hoses .
3) Balance testing , Flotation and deck water-Tight and flotation testing make sure 100% safe "
2) The underfloor fuel tank with cutoff valves and fuel inspection hose with heavy duty fuel hoses .
3) Balance testing , Flotation and deck water-Tight and flotation testing make sure 100% safe "
Factory Information
Taixin Ship is a very professional boat manufacturer with advcanced technology and rich experience.Our products including fishing boat,landing craft,patrol boat,diving boat,passenger boat,rescue boat,fire fighting boating and so on.It is not about lucky in sailing but we believe that the performance when it matters.
