Sofar 15kw 17kw 20kw 22kw 24kw three phase on grid grid tie solar inverter
- Category: >>>
- Supplier: Hefei Pinergy Solar Technology Co. Ltd.
Share on (1600268127354):
Product Overview
Description
Product Description
Specification
Datasheet | SOFAR 10000TL | SOFAR 15000TL | SOFAR 20000TL | |||
Input(DC) | ||||||
Max.Input power | 11000W | 16500W | 22000W | |||
Max DC power for single MPPT | 6750(450V-850V) | 10500(500V-850V) | 12000(500V-850V) | |||
Number of independent MPPT | 2 | |||||
Number of DC inputs | 2 for each MPPT | |||||
Max. input voltage | 1000V | |||||
Start-up input voltage | 350V | |||||
Rated input voltage | 600V | |||||
Mppt voltage range | 250V-960V | |||||
Full load DC voltage range | 350V-850V | 370V-850V | 430V-850V | |||
Max. input current per MPPT | 15A/15A | 21A/21A | 24A/24A | |||
Input short circuit current for each MPPT | 20A | 27A | 30A | |||
Output(AC) | ||||||
Rated power(@230V,50Hz) | 10000W | 15000W | 20000W | |||
Max.AC power | 10000VA | 15000VA | 20000VA | |||
Max.output current | 15A | 22A | 29A | |||
Normal Grid Voltage | 3/N/PE,220/380 or 3/N/PE,240/415 or 3/N/PE,230/400 | |||||
Grid Voltage Range | 180V-270V | |||||
Normal Frequency | 50/60Hz | |||||
Grid frequency range | 47-53/57-63Hz(According to local standard) | |||||
Active power adjustable range | 0-100% | |||||
THDi | <3% | |||||
Power factor | 1(Adjustable +/-0.8) | |||||
Performance | ||||||
Max efficiency | 98.20% | |||||
Weighted eff.(EU/CEC) | 97.6%/97.8% | 97.9%/98% | 98%/98.1% | |||
Self-consumption at night | <1W | |||||
Feed-in start power | 45W | |||||
MPPT efficiency | >99.9% | |||||
Protection | ||||||
DC reverse polarity protection | Yes | |||||
DC switch | Yes | |||||
Protection class/overvoltage category | Ⅰ/Ⅲ | |||||
Input/output SPD(Ⅱ) | Optional | |||||
Safety protection | Anti islanding,RCMU,Ground fault monitoring | |||||
Certification | IEC 62116,IEC61727,IEC61683,IEC60068(1,2,14,30), IEC62109-1/2 CE,CGC,AS4777,AS3100,VDE4105,C10-C11,G59(more available on request) | |||||
SPD | MOV:TypeⅢ standard/TypeⅡ(optional) | |||||
ARPC | Anti Reverse Power Controller(optional) | |||||
Communication | ||||||
power management unit | According to certification and request | |||||
Standard Communication Mode | RS485,Wifi(optional),GPRS(optional),SD card, Multi-function relay | |||||
Operation Data Storage | 25 years | |||||
General Data | ||||||
Ambient temperature range | -25℃...+60℃ | |||||
Topology | Transformerless | |||||
Degree of protection | IP65 | |||||
Allowable relative humidity range | 0...100% no condensing | |||||
Max.operating altitude | 2000m | |||||
Noise | <45dB | |||||
Weight | 45kg | 45kg | 48kg | |||
Cooling | Natural | Natural | Natural | |||
Dimension | 707*492*240mm | |||||
Display | LCD display | |||||
Warranty | 5 years/7 years/10 years | |||||
