1.All of our fishing & working boat are made of Marine-grade aluminum 5083-h116 with China Ship Classification society ( CCS )
a, it is much more durable than fiberglass , steel or wood
b ,It is environment-friendly and can be re-used or recucled .
c ,It is maintenance-friendly and can easily be replaced or repaired when damaged
d, It is much lighter than other material : This means aluminum is more fuel -efficient without sacrificing speed or power .
2.Boat Hull Welding Specification :
1) TIG and MIG are to be adopted for this ship .
2) The ultrasonic inspection to be carried out for the cross joint of seam and other important place .
3) From 5083-H116 material to welding wires to welding use gas & experienced qualified welders .
4) The bottom is double bottom system and constructed on the longitudinal system of framing .
5)Solid floors will be provided at every frame station , the side transverse frames will be fitted at a space of 500mm ."
3.The Core Features Of Our safe Design
1) The Whole hull structure Manual bilge pump system
2) The underfloor fuel tank with cutoff valves and fuel inspection hose with heavy duty fuel hoses .
3) Balance testing , Flotation and deck water-Tight and flotation testing make sure 100% safe "
4.China CCS Standard All of our fishing & working boat are made of Marine-grade aluminum 5083-h116 with China Ship Classification society ( CCS ) .
Why We Stick On CCS Standard :
1) The boat is qualified for the China MSA rules for construction of coastal vessel
2) The boat build as per the China MSA rules for statutory survey of Coastal boats
3) Total vessel production is completed at our factory workshop for a Turn Key Package Options ."
5.CAD / CAM Nesting All the CAD/ CAM Nesting design and building drawing
1) CCS qualified design company for make the drawing
2) Stability report to be fulfilled the request of coastal vessel of MSA .
3) The F.P.T ,void , F.O.T and store are water tight
with aluminum inspection hatches
