BlueRaven PM2401 Have 38mm And 32mm Fixed Hole Only Support ModeB Passive 24V Power Supply Module
BlueRaven PM2401 Have 38mm And 32mm Fixed Hole Only Support ModeB Passive 24V Power Supply Module
BlueRaven PM2401 Have 38mm And 32mm Fixed Hole Only Support ModeB Passive 24V Power Supply Module
BlueRaven PM2401 Have 38mm And 32mm Fixed Hole Only Support ModeB Passive 24V Power Supply Module
BlueRaven PM2401 Have 38mm And 32mm Fixed Hole Only Support ModeB Passive 24V Power Supply Module

BlueRaven PM2401 Have 38mm And 32mm Fixed Hole Only Support ModeB Passive 24V Power Supply Module

Share on (1600281833673):


Price:$1.34 - $1.67

Quantity:


Product Overview

Description


PM2401 Passive POE 24V only support ModeB module power supply


Product Description


product features


 Specification:Short circuit protection


 Security:15-28V input to 12V


 Size :38*19mm





Applications


24V POE power supply





The main parameters






























































NO.

Parameter



Symbol



Min



Typical values



Max



Unit


1

Input Voltage



Vin


1224 30  V
2

output voltage



+VDC


11.812.3 12.8  V
3

output Current



PWR


 1 2  A
4

Storage Temperature



Tj


-40 2.5105

℃


5

Operating Temperature



Tstg


-20 2.570

℃



3.1 is typically 25 ℃, measured under the 24V power supply environment, only for reference design





You are welcome to customize the POE modules of various sizes and appearances and function.
The layout is required to receive the initial research and development expenses.
After ordering a certain number of modules (usually 5000 pieces), the r&d cost can be deducted.
After the sample is qualified, batch production
