12kw Wall Mounted central heating radiant electric combi boiler electr for shower and heating
- Category: >>>
- Supplier: Foshan Zhen Ang Electronic Equipment Co. Ltd.
Share on (1600286456658):
Product Overview
Description
Product Description
Company Profile
Foshan Zhen Ang Electronic Equipment Co., Ltd. Located at Shunde, Foshan China. We have 16 years experiences in researching and producing electric boiler.And OEM and ODM also acceptable.Zhen Ang are devolved to providing good and competitive heating products to our customers.
Company Advantages:
Company Advantages:
1.16 Years In Heating Field
2.OEM/ODM Available
3.3-35 Days Lead Time
4.10,000-20,000pcs/Month Production Capacity
Feature:
Zhen Ang Combi boilers are the perfect electric heating and hot water solution for any property without access to a mains gas supply.Zhen Ang Combi boilers can fit discreetly inside a kitchen cupboard and are powerful enough to provide whole-house heating whilst delivering piping hot water to sinks, basins and showers without the additional cost of installing a hot water cylinder*.
Available in 3 model sizes,Zhen Ang Combi boilers use modulation technology to help minimise running costs and can be programmed via the programmable controller included and any Smart device thanks to built-in WIFI.
* Compact & Stylish Design
* Complete with pump, expansion vessel, automatic air vent and pressure gauge
* Resettable Thermal Cutout
* Near-silent Operation
* Minimal Mechanical Parts
* No flue or fuel supply tank required
* Perfect For Showers
* Can Be Sited Almost Anywhere
* 99.8% Efficient
* Can be controlled from any location
* Compatible with iOS & Android Smart Devices
* Compatible with Alexa and Google Assistance
* 2-Year Warranty
* Extended Warranty Plans Available
* Compact & Stylish Design
* Complete with pump, expansion vessel, automatic air vent and pressure gauge
* Resettable Thermal Cutout
* Near-silent Operation
* Minimal Mechanical Parts
* No flue or fuel supply tank required
* Perfect For Showers
* Can Be Sited Almost Anywhere
* 99.8% Efficient
* Can be controlled from any location
* Compatible with iOS & Android Smart Devices
* Compatible with Alexa and Google Assistance
* 2-Year Warranty
* Extended Warranty Plans Available
Specification
Power (KW)&Voltage Frequency (V/Hz) / Phase | 8kW/220V (Single Phase) | 10kW/220V (Single Phase) | 12kW/220V (Single Phase) | 14kW/380V (3 Phrase) | |||
Service Entrance Wire Size (MM2) | 6mm² | 10mm² | 10mm² | 6mm² | |||
Ammeter Requirement | 60A | ||||||
Electrical Leakage Switch (A) | 50A-2P | 50A-2P | 63A-2P | 50A-3P+N | |||
Heating Area (M2) | ≤80 | ≤100 | ≤120 | ≤140 | |||
Rated Current (A) | 36.4 | 45.5 | 54.5 | 21.2 | |||
First Class Anti-freezing Function Activate Temp. | 8℃ | ||||||
First Class Anti-freezing Function Stop Temp. | 15℃ | ||||||
Second Class Anti-freezing Function Stop Temp. | 5℃ | ||||||
Second Class Anti-freezing Function Stop Temp. | 15℃ | ||||||
Output Voltage of Pump | 220V | ||||||
Water Pump | Grundfos or Made in China | ||||||
Capacity of Expansion Tank (L) | 5L | ||||||
Thermal Cut-out | 140℃ | ||||||
Inlet & Outlet Connection | G1/2" | ||||||
Backwater Inlet Connection | G3/4" | ||||||
Net Weight KGS | 22.9 | ||||||
Gross Weight KGS | 25 | ||||||
Product Size (MM) | 580*360*230 | ||||||
Single Packing Size (L/W/H) MM | 690*430*310 | ||||||
Packing & Delivery
outer carton and inner foam
FAQ
Q1.What’s your electric heating element?
A1. We have both resistance heater and electric magnetic heater.
Q2.Can we do OEM or ODMproduct?
A2. Yes,OEM/ODM is available. We have experiences cooperate with European customer to do ODM electric boiler.
Q3. How long is the delivery time?
A3. Normally 3-45 days, it depends on the orderquantity.
Q4.What is your warranty?
A4. 12th Monthes for the whole product, 1-5 years for the heating element.
Q5. Do your company offer exlusive distributor policy?
A5. Yes. We already cooperate few customers as exclusive distributors.
