Specifications

Carton Size

108*24*45cm

Scooter Size

106*60*120cm

Folded Size

101*17.5*35.5cm

N.W

19.5

G.W

22.65

Handle width

590mm

Folded Handle width

150mm

Pedal width

180mm

Chassis Height

120mm

Performance

Max Load

120kg

Max Speed

37KM/H

Speed Adjustment

3speed 37/32/24

Gradeability

≤15°

Protection Level

IP54

Max Range per Charge

50KM(20KM/HUniform speed)

Battery

Standard Voltage

48V

Battery Type

Lithium Battery

Battery Capacity

13Ah

Motor

Motor Type

Brushless DC motor

Rated Output Power

600W

Maximum Speed

1323(r/min)

Rated Voltage

48V

Maximum output torque

21.58(N.m)

Charger

Output Voltage

54.6V/2A

Charging Time

6.5hours

Braking

Braking Method

EABSElectronic brake + drum brake

Braking Distance

4 meters

Light System

Display

OLED

Front lighting

12VLight Strip

taillight

12V Hawkeye lights

Turn signal

/

Damping system

Front Damping system

Spring damping

Rear Damping system

Spring damping

Tire

Front Tire

8.5inch Pneumatic tire

Rear Tire

8inch Solid tire
