Security guard Policemen police Automated Guided Vehicle / patroling car robot /Security monitoring Collaborative robot kit
- Category: >>>
- Supplier: Guangzhou Emulation Robot Co. Ltd.
Share on (1600290220162):
Product Overview
Description
Security guard Policemen police Automated Guided Vehicle / patroling car robot /Security monitoring Collaborative robot kit
4WD Unmanned logistics vehicle AGV Outdoor patrol car Security monitoring robot for Security guard Policemen
Specifications:
| Specs for ROS chassis | |
| No. | EVO-0010 Evolutionary |
| Size (with anti-collision bar) (customizable): | 1096*799*346(MM) |
| battery capacity | 24V 30AH |
| Motor power (can be set | 200w*4 |
| Battery life | >3H |
| Chassis weight | 68KG |
| Maximum load | >120KG |
| Max Speed | >1M/S |
| Battery voltage | 24V/48V |
| Applicable scene | Space outside/closed group park/inside |
| way of communication | 232 serial port/CAN |
| Transmitter type | High-precision encoder (1024 lines |
| motor | Brushless servo motor |
| System Support | WIN/ROS/UBUNTU/APOLLO |
| Maximum slope (with load) | >25 |
| Minimum turning rich radius | Rotate in place |
| control precision | 1% |
| Ability (vertical ladder) | >8CM |
| Tire diameter | 320MM |
| Drive way | Four-wheel drive (differential drive) |
| Braking method | Servo judgment car (back electromotive force cutting car) |
| Operating temperature | minus 20--60 |
| Chassis optional accessories | |
| Sensor bracket | 1 set |
| Lidar | 1 set |
| touch screen | 1 set |
| Smart module | 1 set |
| GPS module | 1 set |
Applications:
| Size (with anti-control bar) | 1423*866*505(MM) | System supports | WIN/ROS/UBUNTU/APOLLO |
| Motor power (customizable) | 1000WN | minimum turning radius | 2.3M |
| Battery capacity | 48V30AH | control accuracy | given speed ±1% |
| Speed | Maximum 20KMH | Obstacle Crossing | 8-10CMVertical Platform |
| Endurance time | >3H | climbing(load) | 8-10'' |
| Maximum load (customizable) | 150KG | External power supply | 24V/12V/5V |
| Maximum travel speed | 0-20KM/H | Suspension type | Double wishbone independent suspension |
| Battery voltage | 48V | adapts to terrain | indoor and outdoor roads |
| Drive mode | Front steering (Ake quantity control by wire) | Braking mode | Motor brake (reverse electric brake)/Mechanical drum brake |
| Emergency stop button | support | Support Stationary | support |
| Wheel diameter | 360MM | semi-start | support |
| Sensor type | Angle feedback sensor | Wheelbase | 785MM |
| System communication interface | CAN communication | Vehicle material | Sheet metal/metal |
| Accessories for ET-01 series: | |||
| ET-01 series chassis | 1 set | Charger | 1 set |
| ET-1 series shell | 1 set | CAN communication module | 1 set |
| Brushless servo motor | 2 sets | Core VCU control core block | 1 set |
| Brushless Servo Actuator | 2 sets | Multifunctional power supply system | 1 set |
| lithium battery | 1 set | Selector | 1 set |
| Independent suspension | 4 sets | Angle sensor | 1 set |
| Voltmeter | 1 set | speed sensor | 1 set |
| Anti-collision bar | 1 set | Light | 3 sets |
| Optional accessories: | |||
| Unmanned industrial computer | 1 set | 116-line Lidar | 1 set |
| Single-line lidar | 1 set | RTKGPS module | 1 set |
| Small smart camera | 1 set | Trolley bracket (with touch screen) | 1 set |
