Newest technology portable photovoltaic panels half cell 300w 400w solar panel oem solar panel system for home
- Category: >>>
- Supplier: Jiangsu Jingdao New Energy Technology Co. Ltd.
Share on (1600290881022):
Product Overview
Description
STC Electrical performance parameter | ||||||||||||
Model Number | JD300M6C | JD305M6C | JD310M6C | JD315M6C | JD320M6C | |||||||
Component power range | (W) | 300W≤Pm＜305W | 305W≤Pm＜310W | 310W≤Pm＜315W | 315W≤Pm＜320W | 320W≤Pm＜325W | ||||||
The most powerful | Pm(W) | 300W | 305W | 310W | 315W | 320W | ||||||
Maximum working voltage | Vm(V) | 32.8V | 33.0V | 33.2V | 33.5V | 33.7V | ||||||
Maximum working current | Im(A) | 9.15A | 9.24A | 9.36A | 9.41A | 9.50A | ||||||
The open circuit voltage | Voc(V) | 40.1V | 40.2V | 40.3V | 40.8V | 41.0V | ||||||
Short circuit current Isc | (A) | 9.81A | 9.94A | 9.98A | 10.05A | 10.15A | ||||||
The efficiency of the component | (%) | 18.30% | 18.70% | 19.00% | 19.30% | 19.60% | ||||||
Power Tolerance | (W) | 0~+5W | ||||||||||
Temperature Coefficient Pmax | (%/°C) | -0.37 | ||||||||||
Temperature Coefficient Voc | (%/°C) | -0.24 | ||||||||||
Temperature Coefficient Isc | (%/°C) | 0.06 | ||||||||||
Working temperature | (°C) | -40°C ~ +85°C | ||||||||||
The AAA solar simulator(IEC 6094-4),the electrical performance date test uncertainty is between plus or minus 3% | ||||||||||||
