Name | Electronic Components Non Inductive Resistor Wirewound Resistor Fusible Resistor |
Model Number | Electronic Components Non Inductive Resistor Wirewound Resistor Fusible Resistor |
Type | Wirewound Resistor |
Place of Origin | Guangdong, CN |
Brand Name | SHENYIJIA-Technology |
D/C | NKNP Non Inductive Wire-Wound Resistor |
Application | LED Industry, PCB Circuits, Power Supply, Adapters |
Rated Power | 1/4W 1/2W 1W 2W 3W |
Resistance | E-12 Series E-24 Series E-48 Series |
Supplier Type | Original manufacturer, ODM |
Media Available | datasheet, Photo |
Tolerance | ±2% ±5% ±10% |
Technology | Wire-Wound Technology |
Package Type | Throught Hole |
Resistance Tolerance | ±2% ±5% ±10% |
Temperature Coefficient | 300PPM |
Operating Temperature | -55℃~125℃ |
Brand | Shenzhen SHENYIJIA Technology |
Power (Watts) | 1/4W 1/2W 1W 2W 3W |
Composition | Ceramics Rod & Noble Metal Alloy Wire |
Features | High Grade Ceramics Rod |
Coating, Housing Type | Silicone Coated |
Size / Dimension | L: (9-15)mm±1mm D: (3.2-5)mm±0.5mm |
Lead Style | Lead Wire |
Package / Case | Silicon Resin with Indication Code |
Number of Resistors | |
Number of Pins | 2 |
Applications | LED Industry, PCB Circuits, Power Supply, Adapters |
Mounting Type | Leaded/Welding |
Number of Terminations | 2 |
Style | Super SAFE & RELIABLE! |
Tech | Wire-Wound Resistant Alloy Wires |
