100L 200L 300L 500L 1000L 2000L 3000L 5000L Stainless Steel Jacketed Conical Beer Fermentation Fermenter Tank for Sale
- Category: Beverage & Wine Processing Machinery >>>
- Supplier: Jinan,Rainbow,Machinery,Co.,Ltd.
Share on:
Product Overview
Description
Rainbow Factory Supply Jacketed Conical Beer Fermentation Tank
Capacity: 100L 200L 300L 500L 1000L 2000L 3000L 5000L 10000L...
1BBL 2BBL 3BBL 5BBL 7BBL 10BBL 20BBL 60BBL 120BBL...
Capacity: 100L 200L 300L 500L 1000L 2000L 3000L 5000L 10000L...
1BBL 2BBL 3BBL 5BBL 7BBL 10BBL 20BBL 60BBL 120BBL...
Main Configurations
Beer Fermenting Vessel/Brites
Total capacity: with 25% headspace
Dome top and cone bottom, bottom cone, (60 degree for BFV)
Interior Shell: SUS304, T 3.0mm;
Exterior Shell: SUS304, T 2.0mm;
Insulation: PU, T100mm
100% TIG welding with pure argon gas shield
Interior Finish: to 0.4~0.6μm/ Mirror polishing
Cooling Jacket: both on cone and cylinder parts
Top mounted manhole/Side manhole
Relief/vacuum valve
Dry hop port
Thermometer
Sample valve
Bung apparatus with pressure gauge
Test Pressure: 0.3Mpa, Working pressure: 0.15-0.2Mpa.
Rotating racking arm on cone with butterfly valve
Drainage with butterfly valve
CIP arm with 360° spraying ball
Thermowell with high accuracy temperature sensor: PT100
Total capacity: with 25% headspace
Dome top and cone bottom, bottom cone, (60 degree for BFV)
Interior Shell: SUS304, T 3.0mm;
Exterior Shell: SUS304, T 2.0mm;
Insulation: PU, T100mm
100% TIG welding with pure argon gas shield
Interior Finish: to 0.4~0.6μm/ Mirror polishing
Cooling Jacket: both on cone and cylinder parts
Top mounted manhole/Side manhole
Relief/vacuum valve
Dry hop port
Thermometer
Sample valve
Bung apparatus with pressure gauge
Test Pressure: 0.3Mpa, Working pressure: 0.15-0.2Mpa.
Rotating racking arm on cone with butterfly valve
Drainage with butterfly valve
CIP arm with 360° spraying ball
Thermowell with high accuracy temperature sensor: PT100
Optional:
Level Tube
CO2 Carbonation Stone
Copper Shell
Pressurized Hop drop feeder
Other requirements
Dimension design
Product Description
Beer Fermentation Tank For Beer brewery
Total Volume: with 25% head space
Dimension: ø1200mm*H2650mm
Inner: SUS 304 T3mm;
Layer: SUS 304 T2mm;
Jacket: SUS 304 Dimple Plate T1.5mm
Insulation: PU 100MM
Other Configurations | |
Top | Dome Top, with ratating CIP ball TC |
Bottom | Conical 60 Degree with Drainage Valve |
Jackets | Both on Bottom and Cylinder Parts |
CIP | CIP Arm with Rotating ball, Butterfly valve |
Valves | Safety/Vacuum Valve, Sample Valve |
Outlet | Rotation Rack Arm SMS76*32TC Valve |
Temp. | Thermometer and PT-100 |
Testing | Test:0.3Mpa, Working: 0.15-0.2Mpa |
Pressure | Bung Apparatus with Pressure Gauge |
Polishing | 0.4-0.6μm/ or Mirror polishing |
Legs | 4 legs with adjustable Bolts |
Cooling | Cooling ports, Threads ø25mm |
Parts | With gaskets, Cooling pipe fittings |
Detailed Images
Regular with Top Oval Manhole
Optional :
Optional :
Side Manhole
CO2 Carbonation Stone
Level Tube
Company Introduction
Packing&Shipping
For Less Container Loading:
Carbon steel with PLY wooden package suitable for long marine transport
For Full Container Loading
PE Stretch film with soft material outside protecting
PE Stretch film with soft material outside protecting
