Hongsen hand tool valve or KM diaphragm hand valve 1/4
- Category: >>>
- Supplier: Guangzhou Baida Refrigeration Equipment Co. Ltd.
Share on (1600296452269):
Product Overview
Description
Product Description
KM Diaphragm Hand Valve
·Model KM hand valve is a manually operated diaphragm stop valve for one-way flow control.
·Model KM hand valve is mounted on the liquid, air suction and hot air piping in the refrigeration, cold storage and air conditioner.
·Two types of connection are available for Model KM hand valve, that is, threaded connection (SAE) with threading size 1/4 SAE to 3/4 SAE and welded connection both ODF, structure hand valves have connection size 1/4” to 7/8”.
·All Model KM hand valves are equipped with mounting hole for the installation on the instrument panel.
| Model | Flare | Welded (with copper tube) | Kv(m3/h) |
| KM-1/4" | 1/4“ SAE | 1/4“ ODF | 0.28 |
| KM-3/8" | 3/8“ SAE | 3/8" ODF | 0.30 |
| KM-1/2" | 1/2“ SAE | 1/2" ODF | 1.30 |
| KM-5/8" | 5/8“ SAE | 5/8" ODF | 1.80 |
| KM-3/4" | 3/4“ SAE | 3/4" ODF | 3.65 |
| KM-7/8" | 7/8" ODF | 3.65 |
