300 dpi 600 dpi fast barcode thermal transfer label tto printer for packaging bag
- Category: >>>
- Supplier: Chengdu Linservice Industrial Inkjet Printing Technology Co. Ltd.
Share on (1600301366340):
Product Overview
Description
Products Description
Brief introduction
The TTO printer can form printing on the packaging material through the relative movement of the print head and ribbon with the packaging material. It is suitable for printing variable codes (including traceability code and bar code) of various flexible packages such as food, medicine, daily chemical and household paper.
Technical specification | ||
Product name | Barcode thermal transfer label tto printer | |
Order Code | LS-T320S (intermittent), LS-T320F (continuous)/LS-T530S (intermittent), LS-T530F (continuous) | |
Structure | All-metal structure | |
Print mode | Hot transfer printing | |
Maximum print width | 32 mm (300dpi)/53 mm (300dpi) | |
32mm*75mm (intermittent), 32mm*100mm (continuous)/53mm*75mm (intermittent), 53mm*100mm (continuous) | ||
Resolving power | 300 dpi (12 dots/mm) | |
Printing speed | 40 - 600mm/s | |
Processor | 32-bit RSIC Processor | |
Flash Memory | Minimum 8MB | |
Dynamic memory | Minimum 16MB | |
Instant Clock Function | STD, battery discharge life of at least 3 years | |
Color band tension detection;Hot Writer Position Detection;Open cover detection;Hot Writer Overtemperature Detection;Carbon Belt Break Detection | ||
Soft Package Detection | Electromagnetic Induction or Synchronizer | |
PVDC, PET, PE, NY, CPP, OPP, BOPP, BOPET, BOPA, CPP, PE, VMPET, VMCPP and other films and composite films | ||
Carbon belt capacity | 1"MAXIMUM LENGTH 1100M | |
Carbon belt savings | Resin width: 20 mm (0.79") to 55 mm (2.17") | |
Carbon belt types | Type: Wax/Resin | |
Air pressure supply | Supports staggered, radial, multi-print signal, digital carbon belt saver printing, carbon belt retreat and other carbon belt Saver modes | |
Air consumption | Minimum carbon band spacing between two lines of printing is not more than 0.5mm | |
Print Concentration Order | Maximum 6 bar/90 PSI | |
USB interface | As low as 4 ml/print at 2.5 bar | |
USB Host Interface | Step 31 | |
Serial port | STD1 Port, Type B Connector, USB Device 2.0 | |
Ethernet interface | STD1 USB Disk Connection Port USB Host 2.0, Automatic Detection and Setup of Connections | |
Power supply | Internal switching power supply module, I/P:AC90V-264V, 47/63Hz;150VA | |
Hardware Interface Interface | Input: "Print start" and a configurable input Output: Fault, Warning and Two Configurable Outputs | |
Software | HPRT Format Editor | |
environment condition | Operation: 0-40 @ humidity 10%-90% without condensation Storage: -40-60 @ humidity 10%-90% without condensation | |
Printing device: height less than 190mm, width less than 220mm and depth less than 236mm Controller: Height less than 170mm, width less than 263mm and depth less than 190mm | ||
Machine weight | Printing device: less than 8kg, controller: less than 5kg | |
Logistics Packaging Weight | 13KG | |
Logistics Packaging Size | 565*330*528 mm | |
Company Profile
Located in Chengdu, Sichuan Province, China, the hometown of giant panda, Chengdu Linservice Industrial Inkjet Printing Technology Co., Ltd. has become a leader in the product identification industry with its strong technical strength, complete production equipment, strict quality testing, mature manufacturing.
As a professional inkjet printer product provider, it has professional technology and product resources and focuses on the product identification and safety of the enterprise. With more than nearly 20 years of service experience in the identification industry, it provides safe, assured and reliable product identification for all sectors of society, especially in the association and traceability application of industrial identification.
As a professional inkjet printer product provider, it has professional technology and product resources and focuses on the product identification and safety of the enterprise. With more than nearly 20 years of service experience in the identification industry, it provides safe, assured and reliable product identification for all sectors of society, especially in the association and traceability application of industrial identification.
Exhibition
Certificate
Partner
Our partner
Linservice has been a qualified supplier of P & G (China) Co., Ltd. for many years. The well-known customers include: P & G (China), Lafarge (China), Coca Cola, unified enterprise, Wuliangye Group, Jiannanchun Group, Luzhou Laojiao group, Tsingtao Beer Group, China Resources Lanjian group, Di'ao pharmaceutical group, China Biotechnology Group, Sichuan ChuanHua group, Lutianhua group, Sichuan Tianhua group, Zhongshun group, Chengdu new hope group, Sichuan Huiji food, Sichuan Liji group, Sichuan Guangle group, Sichuan coal group, Sichuan Tongwei group, Sichuan xingchuancheng group, Sichuan Jiahua group, Yasen building materials, Chongqing beer group, Chongqing Zongshen electric appliance group, Guizhou Hongfu group, Guizhou saide group, Guiyang snowflake beer, Guizhou Deliang prescription pharmaceutical, Yunnan Lancangjiang beer group, Kunming Jida Pharmaceutical Group, Kunming
Jinxing Beer, There are hundreds of enterprises in Yunnan Wuliang zangquan, Gansu Jinhui liquor group, Gansu Duyiwei Co., Ltd., including food, beverage, pharmacy, building materials, cable, chemical industry, electronics, tobacco and other industries.
Jinxing Beer, There are hundreds of enterprises in Yunnan Wuliang zangquan, Gansu Jinhui liquor group, Gansu Duyiwei Co., Ltd., including food, beverage, pharmacy, building materials, cable, chemical industry, electronics, tobacco and other industries.
The products have been also exported to more than 30 countries, such as the United Kingdom, Russia, Saudi Arabia, the United Arab Emirates, Poland, Ukraine, India, Korea, Singapore, Brazil and Peru.
FAQ
1. How to guarantee quality?
From production to sale, the machine is checked at every step to ensure that the final equipment is in order.
2. Can you guarantee the safety in transit?
It can ensure the safety in transit. Our packing is very strict.3.Will you provide after-sale technical service?
We will provide 24 hours after-sales service, we will also have technical staff to answer your questions
4. Can I repair it if it breaks down?
Can repair
5. Where can these devices be used?
Our products cover printing and packaging, food and beverage, chemical building materials, pharmaceutical, tobacco, daily chemical, automotive and aerospace manufacturing and many other industries.
6. How do I know if your machine works well?
Before delivery, we have tested each machine and adjusted it to the best condition. If you have special production conditions, we will adjust to the corresponding state for you.
From production to sale, the machine is checked at every step to ensure that the final equipment is in order.
2. Can you guarantee the safety in transit?
It can ensure the safety in transit. Our packing is very strict.3.Will you provide after-sale technical service?
We will provide 24 hours after-sales service, we will also have technical staff to answer your questions
4. Can I repair it if it breaks down?
Can repair
5. Where can these devices be used?
Our products cover printing and packaging, food and beverage, chemical building materials, pharmaceutical, tobacco, daily chemical, automotive and aerospace manufacturing and many other industries.
6. How do I know if your machine works well?
Before delivery, we have tested each machine and adjusted it to the best condition. If you have special production conditions, we will adjust to the corresponding state for you.
