Infrared Paint Curing Lamp Moveable Short Lamp for Spray Booth LD 1H

Applicable voltage: 220V-240V 50/60HZ
Power: 1 x 1100W
Temperature: 40 ℃ -100 ℃
Baking area: 650 × 500mm

It can rotate 360° on the holder from top and down. The highest can reach the car’s top. And also can move to use as hand hold
model.
Voltage: 220V-240V 50/60HZ
Power: 1 x 1100W
Temperature: 40℃ -100 ℃
Baking area: 650× 500mm Package : 53cm-47cm-27cm 3.8cm-3.8cm-150cm Weight :10.2kg+1kg=11.2kg

Floor Filter Cotton

Fiberglass floor filter: installed under grilles for full downdraft spray booth; installed on exhaust cabinet for semi downdraft
spray booth. It is used to prevent paint mist going outside. Recommended time for changing: 40-60 working hours

It can move up and down,the highest to the car’s top. Only with simple knob to set time. Voltage: 220V-240V 50/60HZ
Power：2×1100W
Temperature: 40℃-100 ℃
Working Time: 0-60m
Baking Area：800×800mm Package :74cm-64cm-27cm 6cm-6cm-153cm Weight : 24kg

It can move up and down,the highest to the car’s top. High quality electric control box
Voltage: 220V-240V 50/60HZ
Working Time: 0-60m
Temperature: 40℃-100 ℃
Power：2×1100W
Baking Area：800×800mm Package :74cm-64cm-27cm 6cm-6cm-153cm Weight : 24.5kg

It can move up and down,the highest to the car’s top.
Standard control box, a small circuit board, SCR, thermostat.
Voltage: 220V-240V 50/60HZ
Working Time: 0-60m
Temperature: 40℃-100 ℃
Power：2×1100W
Baking Area：800×800mm Package :74cm-64cm-27cm 6cm-6cm-153cm Weight : 24.5kg

Voltage: 220V-240V 50/60HZ
Power：3×1100W
Working Time: 0-60mm Temperature: 40℃-100 ℃
Baking Area：1200×1000mm
Operation: Computer board touch control

Voltage: 220V-240V 50/60HZ
Power：3×1100W
Working Time: 0-60m
Temperature: 40℃-100 ℃
Baking Area ： 1200 ×1000mm
Operation: Computer board touch control, with pulse Punching function, easy to set plating coating, gold ash
Power and time functions

Voltage: 220V-240V 50/60HZ
Power：3×1100W
Working Time: 0-60m
Temperature: 40℃-100 ℃
Baking Area ： 1200 ×1000mm
Operation: Computer board touch control, pulse function, distance sensing preheating function, operating language can be switched
between Chinese and English

Voltage: 220V-240V 50/60HZ
Power：3×1100W
Working Time: 0-60m
Temperature: 40℃-100 ℃
Baking Area ： 1200 ×1000mm
Operation: Computer board touch control, with pulse function, large computer board can upgrade temperature measurement and ranging
function, large screen four-digit display temperature and time, etc.

Voltage: 380V 50/60HZ
Power：6×1100W Working Time:0-60m Temperature: 40℃ -100 ℃
Baking Area1200×2000mm
Operation: Screen Touch with pulse function

【product description】
Imported rotary torsion mechanical set time and temperature function, hydraulic lifter, lamp body can be rotated 360 degrees,
there is automatic alarm ringtone when setting time, can control each group of lights independently, can move in all directions in
the paint room Convenient and practical, saving costs. The vertical and horizontal guide rails on the top of the baking room can
make the baking lamp move freely in all directions. The two-section variable angle swing arm can make the lamp body act on any
position in the baking room, and the lamp body is lifted and assisted by the gas spring.
Voltage: 220V-240V,380V for 6 lamps.
Power: 1100W per piece
Temperature: 40℃-200℃
Time：0min-60min
Baking Area：1200×1000mm

3pcs infrared lamps in one box, every box with cover for protection
