Raycus fiber laser source generator RFL C1000 RFL C1500 RFL C2000 RFL C3000 for fiber laser cutting machine
- Category: >>>
- Supplier: Shenzhen Dahan Laser Equipment Co. Ltd.
Share on (1600310037699):
Product Overview
Description
Related Products
Product Description
Have higher photoelectric conversion efficiency, better, more stable beam quality, more powerful anti-high-counter capability, and introduce an optimized second-generation fiber transmission system to ensure a more stable and precise cutting effect in thick plate cutting. . This product is suitable for a variety of applications: cutting, welding, punching, medical device processing, etc., cutting sheet cuts narrow and brighter, relative to the other similar lasers in the market.
Detailed Images
Features Good compatibility :
Can adapt to a number of manufacturers 80W sealed off CO2 laser tube, but also has strong adaptability and fast response,
engraving, cutting benefits good effect.
Control is simple:
Select high or low level control, the use of TTL-level control of the laser can start and stop. At the same
time increase the protection switch, testing is through the external water and ventilation.
time increase the protection switch, testing is through the external water and ventilation.
Protection Function:
Power supply itself has open circuit protection, a good grounding in the case of protection, the power
supply to short-term work in the open state, so to avoid the laser tube burst due to the damage caused by laser power supply,
thereby enhancing the laser power supply of life.
supply to short-term work in the open state, so to avoid the laser tube burst due to the damage caused by laser power supply,
thereby enhancing the laser power supply of life.
Specification
Features | ||||
High electro-optical | conversion efficiency | Output fiber length can be | customized | QBH connector |
frequency range | Width modulation | Thin plate cutting efficient | Maintenance | Anti-high anti-ability |
Optical characteristics | ||||
Average output power: (W): 1000 | Center wavelength: (nm): 1080 ± 5 | Maximum modulation frequency: (kHz): 5 | Output power stability: ± 1.5% | Red light: there is |
Output characteristics | ||||
Output connector: QBH (can be customized) | Beam quality m2: 1.3 (25μm) | Polarity: random | Output fiber length (m): 20 (can be customized) | |
Electronic control characteristics | ||||
Input Power (VAC): 200-240, single phase | Control mode: external RS232, external AD, super terminal | Power adjustment range (%): 10-100 | ||
Other features | ||||
Size (mm) width * height * Deep: 485 * 748 * 237 (including handle) | Weight (kg):<50 | Cooling method: water cooling |
Company Profie
Shenzhen Dahan Laser Technology Co., Ltd. was established in 2008, currently employs more than 400 people, has more than 20 branches across the country, and has 4 production bases in Shenzhen, Dongguan, Wenzhou, and Kunshan. Dongguan cutting machine production base covers an area of more than 10,000 square meters. Dahan is a national laser equipment high-tech enterprise integrating R&D, production, sales and service. Dahan is committed to laser technology research and development, laser equipment design research and development, production, technical support, service and consulting, and strives to become a leading brand in the laser industry.
Main products: laser cutting machine, laser welding machine, laser cutting and welding robot, laser marking machine, industry-specific laser cleaning machine and automatic laser equipment, etc.
2008 The company was established.
2009 launched the laser marking machine series.
2010 launched laser welding machine series.
2011 launched laser welding and cutting machine series.
2012 Established Wenzhou Kunshan Xiamen Branch
In 2013, 35 national offices were established.
In 2014, product sales exceeded 3,000 units per year.
2015 Dongguan Laser Cutting Equipment Factory was established, covering an area of more than 10,000 square meters.
In 2016, a large-scale gantry milling machine processing center in Dongguan was established, and a sheet metal processing center for cutting machines was established to provide services for cutting machines and sheet metal.
In 2017, the government issued the national high-tech enterprise certificate, and MAX Laser awarded its strategic partners a medal with an annual sales volume of more than 3,000 units.
2008 The company was established.
2009 launched the laser marking machine series.
2010 launched laser welding machine series.
2011 launched laser welding and cutting machine series.
2012 Established Wenzhou Kunshan Xiamen Branch
In 2013, 35 national offices were established.
In 2014, product sales exceeded 3,000 units per year.
2015 Dongguan Laser Cutting Equipment Factory was established, covering an area of more than 10,000 square meters.
In 2016, a large-scale gantry milling machine processing center in Dongguan was established, and a sheet metal processing center for cutting machines was established to provide services for cutting machines and sheet metal.
In 2017, the government issued the national high-tech enterprise certificate, and MAX Laser awarded its strategic partners a medal with an annual sales volume of more than 3,000 units.
Whenever you visit Dahan's production base, you can see all the real machines. Here, you can see detailed information about the production and processing of machine tool tables, sheet metal processing, machine tool assembly and debugging. Because we have enough orders and are in production. Daehan’s annual sales are far ahead of its peers. Relying on the resources and price advantages of various brands, Daehan is willing to share resources with partners through large-scale purchases to reduce costs.
Dahan provides OEM services and recruits agents from all over the world. Welcome to visit our factory.
Dahan provides OEM services and recruits agents from all over the world. Welcome to visit our factory.
Company Team & Exhibition
After-sales service
1. OEM Manufacturing welcome: Product, Package... 2. Sample order
3. We will reply you for your inquiry in 24 hours.
4. after sending, we will track the products for you once every two days, until you get the products. When you got the
goods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offer
the solve way for you.
FAQ
How to choose right power laser source?
It depends on your cutting work request:
1. What is the metal will you cutting?
2. What is the max and mainly thickness will you cutting?
3. Can cut through plate doesn’t mean is cutting quality,cutting effectiveness,it depends on your mainly cutting thickness,cutting work request and budget.
Please make sure mainly cutting work request and budget before buy.
It depends on your cutting work request:
1. What is the metal will you cutting?
2. What is the max and mainly thickness will you cutting?
3. Can cut through plate doesn’t mean is cutting quality,cutting effectiveness,it depends on your mainly cutting thickness,cutting work request and budget.
Please make sure mainly cutting work request and budget before buy.
Contact Us
We are manufacturer of fiber laser cutting machine with 12 years of production experience.We offer complete machine solution,also provide laser source,CNC controller ,laserhead, water chiller,servo,custom made machine table,training and service,etc. one-stop solution!
If you need other products,Contact us freely!
If you need other products,Contact us freely!
