Structure Prefabricated House Cheap Construction Steel Custom Color Material Origin Sheet Place Model Panel Customers Sandwich

Standard house

Size(mm)

5850*2430*2896mm (L*W*H)

Roof shape

Flat roof with internal drainage

Floor

1Storeys

Structure

Corner post, roof and floor beam, column

Galvanized cold rolled steel, thickness 2.0-2.5mm, zinc content 80-150g/m2

Paint

Graphene powder electrostatic spraying, thickness 80-100μm

Roof

Roof sheet

Galvalume color coated steel sheet, white gray, 3%-5% slop

Insulation material

50mm thickness fiberglass roll with single aluminum foil, density 15kg/m2, A grade fireproof property

Ceiling

0.5mm thickness color coated steel sheet, model V831/V193 for option

Floor

Decoration

2.0mm thickness PVC floor

Base plate

16mm thickness MGO board

Moisture-proof film

Specialized PE moisture-proof film

Optional

Insulation material ,Sealing bottom plate

Wall

Thickness

50/75mm fiberglass sandwich panel, two side galvalume steel sheet thickness 0.4-0.5mm

Appearance

Outer orange peel grain, inside flat

Insulation

50/75mm fiberglass, density≥50kg/m, combustion performance is a grade

Door

Can be customized

Standard is 840*2035mm, specially made fireproof steel door

Windows

Can be customized

1120*1100mm, PVC double glazing with screen window and security bar

Electrical and pipeline

Prefabricated, as your requested standard

Optional

Bathroom fittings, kitchen fittings, furniture
