A variety of connectors to facilitate the user to select 5PIN;
Pressure Range
0 ~ 0.5 MPa ~ 150 MPa ( 0 ~ 100psi ~ 20000psi )
Accuracy:
±1.0% FS
Output signal:
Current signal: 4~20mA, 0~20mA; Voltage signal: 0~10V, 0~5V, 1~10V, 1~5V.
Temperature drift:
≤ 0.3MPa/100 ℃;
Probe Max Temperature:
400 ℃;
Thermometric Config:
Thermocouple: NO.,
Insulation Resistance
>=500MΩ/500VDC
Order Format:
Example1: PT1116B-350bar-M18-150-0~10V Note: Product design Model "PT1116B". Function code "B" stands for melt pressure transmitter. Coating code "Null" stands for without coating . Pressure range: 0 ~ 350bar. Thread size : M18 * 1.5. Rigid stem length:150mm . Pressure output signal: 0~10V.
Example2: PT1236B-5000psi-1/2"-20-150/470-4~20mA Note: Product design Model "PT1236B". Function code "B" stands for melt pressure transmitter. Coating code "Null" stands for without coating . Pressure range: 0 ~ 5000 psig. Thread size : 1/2"-20UNF . Rigid /Flexible length:150mm/470mm . Pressure output signal: 4~20mA
Example3: PT1316B-50MPa-1/2"-20-150/470-Pt100-4~20mA Note: Product design Model "PT1316B". Function code "B" stands for melt pressure transmitter. Coating code "Null" stands for without coating . Pressure range: 0 ~ 50MPa. Thread size : 1/2"-20UNF . Rigid /Flexible length:150mm/470mm . Thermometric Config : Pt100 Thermal Resistance Temperature Sensor . Pressure output signal: 4~20mA .
Our Services
18 Months Warranty
Company Profile
Yuanda electronics focuses on the research and innovation of sensor technology, focusing on the accurate measurement and perfect control of high temperature melt pressure and temperature. The products have been widely used in chemical fiber textile, rubber and plastic, new materials, nonwovens, water treatment, aerospace, military, petroleum, chemical, power station, automation equipment manufacturing, pharmaceutical, food and other industries.
Quality assurance Products are manufactured in strict compliance with ISO and CE directives and in full compliance with RoHS requirements. Based on large production plants and excellent international equipment, Yuanda Electronics is recognized for its inspection, testing and calibration throughout the world and provides experienced OEM services. The sales and after-sales technical service team has won the good reputation and great trust of thousands of customers around the world
Application Field
MT Series melt temperature sensors are suitable for petrochemical, textile and plastics, rubber, non-woven fabric industry melt, fluid, gas temperature measurement. Temperature sensor probe with a cone or ship structure, the flow resistance in reducing medium, while the sensitive parts of the probe measured entirely in the medium to ensure greater accuracy of measurement , shorter response time, better reliability . The advantages of this kind of products including good stability, installation easily, beautiful appearance, and good quality
Packing & Delivery
FAQ
Q:What kind of products do you offer ?
A: supply pressure sensors, level sensors, temperature sensors, flow meter . Export more than 70+ countries
Q:Could I get samples?
A:Yes, we have half-stock ready products for customized sample
Q:What is the delivery time?
A:For standard specification, delivery time 5-7days. For customized specification 10-20days
Q: What is your terms of payment ?
A: We could accept T/T, Paypal, WU .trade Assurance
Q: What is the warranty for your product ?
A: Warranty: 12-24Month, Lifetime maintenance
Q: How can I get the quotation or send my inquiry to?
A: Send your inquiry to us by the inquiry from on the right-side or the bottom of
this page.
1. What is the measuring medium?
2. How about measuring range ?
3. What would be the processing pressure and temperature ?
4. Which signal output:4-20mA,?
5. Require quantity?
