Aluminum Frame Back Light 2 by 2 and 2 by 4 Led Backlight Panel Backlit With Lens High Quality
- Category: >>>
- Supplier: Zhongshan Qisen Lighting Company
Share on (1600315047751):
Product Overview
Description
Aluminum Frame Back Light 2 by 2 and 2 by 4 Led Backlight Panel Backlit With Lens High Quality
Product Description
Brand | Qisen / OEM | Model | QS-TBP-36 |
Input Voltage(V) | 85-265 | Power | 36W / 40W / 48W |
Luminous Flux | 3600 / 4000/ 4800lm | CRI (Ra>) | 80 |
Temperature | -20~50℃ | Lifetime | 25000h |
IP Rating | IP20 | Back Cover | Iron |
Cover Material | Aluminum | Frame Material | Aluminum |
Light source | LED | LED Chips | SMD2835 |
CCT | 3000K/4000/6500K | Beam angle | 120° |
Light Color | natural / warm / cold | Installation | Recessed |
Product Feature
- Innovative product,Light is even, no dark area
- Compared with flat panel, backlit is more competitive,20-30% cheaper than side light
- Compared with 3.0cm backlit, the volume and transportation cost are reduced by one third
- No LGP,No yellowing for three to five years
- More than twenty configurations to meet different need
- Chip's working temperature is low, lengthen lifespan
- Chip:Lmported high lumen copper 2835 chip, high temperature resistance & long lifespan
- Good quality aluminum, good heat sink
Product Details
| Led Backlit Panel Light | ||||||
| Model | Thickness | Size | Power | Luminous Flux | Lamp beads | IP Rating |
| QS-BP-36 | 2.0cm | 600*600mm | 36W | 3600Lm | 64 | IP20 |
| QS-BP-40 | 2.0cm | 600*600mm | 40W | 4000Lm | 64 | IP20 |
| QS-BP-48 | 2.0cm | 600*600mm | 48W | 4800Lm | 64 | IP20 |
| QS-TBP-36 | 3.0cm | 600*600mm | 36W | 3600Lm | 48 | IP20 |
| QS-TBP-40 | 3.0cm | 600*600mm | 40W | 4000Lm | 48 | IP20 |
| QS-TBP-48 | 3.0cm | 600*600mm | 48W | 4800Lm | 48 | IP20 |
| QS-TBP13-36 | 3.0cm | 300*900mm | 36W | 3600Lm | 48 | IP20 |
| QS-TBP13-40 | 3.0cm | 300*900mm | 40W | 4000Lm | 48 | IP20 |
| QS-TBP13-48 | 3.0cm | 300*900mm | 48W | 4800Lm | 48 | IP20 |
| QS-TB2*4-100 | 3.0cm | 600*1200mm | 100W | 9500Lm | 96 | IP20 |
More detail information, please just feel free to contact us.
Packaging & Shipping
Our Products: | Panel light, Downlight,Tube light, Batten light, Bulb light, Track light >>HOMEPAGE |
MOQ: | Small order can be acceptable; |
Packing: | According to customer requirements |
Delivery Time: | Shipped in about 30 days after payment; |
Supply Ability: | 30000 pieces per Month; |
Payment Terms: | L/C, T/T, Western Union, MoneyGram, Cash |
Shipping way: | Sea or air transportation; Port of Loading: Guangzhou/Shenzhen |
Company Information
FAQ
Q 1. Can you provide free samples?
A. Yes, but you need to pay for shipping.
Q 2. What about the delivery time?
A. 3 days for sample,25-30 days for mass order.
Q 3. Do you have a MOQ limit?
A. We accept trial order.
Q 4. What is your warranty?
A. 1-5years,depend on your need.
Q 5. Can I print my logo on led products?
A. Yes,customized package and product is available.
