High quality 25x62x20.6mm LR5205ZZ yoke type track roller bearing LR5205ZZ LR5205 2RS LR5205NPP bearing
- Category: >>>
- Supplier: Shandong Hanke Bearing Co. Ltd.
Share on (1600317075142):
Product Overview
Description
High quality 25x62x20.6mm LR5205ZZ yoke type track roller bearing LR5205ZZ LR5205-2RS LR5205NPP bearing
PRODUCT SPECIFICATIONS
Bearing number | LR5205ZZ bearing |
Inner diameter | 25mm |
Outer diameter | 62mm |
Width | 20.6mm |
Dynamic load rating | 19.7KN |
Static load rating | 15.9KN |
Reference speeds | 6500 r/min |
Weight | 0.34kg |
PRODUCT DESCRIPTION
Yoke type ball bearing track rollers are ready-to-fit, single or double row rolling bearings based on deep groove or angular contact ball bearings.
They have particularly thick-walled outer rings with a crowned outside surface (also available with a cylindrical outside surface on request), can support high radial loads and tolerate axial loads which are due to small mis-alignments, skewed running or temporary contact running impacts.
Yoke type ball bearing track rollers are mounted on a shaft or stud with a stationary inner ring. They are not mounted in a housing bore but supported on a flat raceway (mating track).
Yoke type ball bearing track rollers are sealed with a lip seal or a sealing shield on both sides.
They have particularly thick-walled outer rings with a crowned outside surface (also available with a cylindrical outside surface on request), can support high radial loads and tolerate axial loads which are due to small mis-alignments, skewed running or temporary contact running impacts.
Yoke type ball bearing track rollers are mounted on a shaft or stud with a stationary inner ring. They are not mounted in a housing bore but supported on a flat raceway (mating track).
Yoke type ball bearing track rollers are sealed with a lip seal or a sealing shield on both sides.
