specifications | |
power supply(option) | |
power consumption | 30VA |
WEIGHT | 10KG |
installation style | plain base installation/vehicle |
relative humidity | 10-90% |
operation temperatrue | -35C~-55C |
Waterproof class | IP66 |
MODLE | 18x | 23x | 27x | |
image inductor | 1/4'' color CCD | |||
effective pixels | 752H*582V | 795H*596V | ||
inside | ||||
automatic/manual | ||||
15.625KHz(H)50Hz(V) | ||||
480TVL | ||||
>50db | >48db | |||
1/3~1/10000sec | 1/50~1/10000 | |||
lowest LUX | 0.01~1LUX | |||
focusing range | f=4.1~73.8m | f=3.6~82.8m | ||
Iris&Zoom | automatic/manual |
pan movement | 100/s max | |||
tilt movement | 100/s max | |||
preset position | 128 positions in maximum | |||
patrol function | 6 patrol patterns are stored in maximum | |||
scanning speed | 0.5~30/sec | |||
self-study pattern | 40sec | |||
infared illuminator | high brightness LED*36pcs | |||
wavelength | 850nm | |||
project distance | 120m | |||
power consumption | 4W | |||
control of infared | auto/manual control on menu | |||
service life of infared | over 20000 hours | |||
Four channel inputs | normal open,closing for alarm | |||
one channel output | normal open normal close output |
