Price:$4,200.00 - $4,500.00

Quantity:


Product Overview

Description



800 Channels High Precision Foif A90 A60pro gps rtk south Galaxy G1 gnss rtk System With tilt chc i73 base and rover


Products Description




Exhibition






Technical parameter





GNSS Performance
Channels
800
GPS
GPS：L1C/A，L1C，L1P(Y)，L2C，L2P（Y），L5
GLONASS
G1P1，G2P2，G1OC，G2OC，G3OC
Galileo
E1BC、E5a，E5b，E5ALTBOC、E6BC
BeiDou
B1, B2, B3
SBAS
L1
QZSS
L1CA，L2C，L5，L1C，LEX
L-Band


GNSS Accuracies

Real time
kinematics (RTK)
Horizontal: 8 mm + 1 ppm RMS
Vertical: 15 mm + 1 ppm RMS
Initialization time: < 10 s
Initialization reliability: > 99.9%
Positioning rate
5 Hz






Hardware
Size (L x W x H)
φ156mm×76mmH
Weight
1.2kg


Environment
Operating:-30°C to +65°C
(-40°F to +149°F)
Storage: -40°C to +80°C
(-40°F to +185°F
Ingress protection
IP67 waterproof and dustproof, protected
from temporary mmersion to depth 1m

Tilt sensor
Calibration-free IMU for pole -tilt
compensation.Immune to magnetic
disturbances.
Front panel
4 status indicators and power indicator




Communication
Wi-Fi
802.11 b/g/n, access point mode
Bluetooth
V2.1+EDR/V4.1 dual mode, Class2
Others
NFC


UHFradio
Transmitting power: 1w, frequency: 410-470MHz
Radio protocol: SATEL, PCC-EOT, TrimTalk450S, South9600, South19200, Hi-Target9600, Hi-Target19200, TrimMarkIII (19200),
TrimMarkI, GEOTALK, GEOMARK
Data storage
8 GBinternal memory



Electrical
Input voltage
DC 9V-18V
battery capacity
7.2v，24.5wh（standard two batteries）
battery Life timer
Static survey：15 hours，
rover rtk survey：12h



Company Profile




Chengdu Zhicun Space Surveying and Mapping Instrument Co.Ltd inJanuary 2019,is a professional manufacturer andexporter that is concerned with the sale, development and production ofSurveying instrument. We are located inChengDu, with convenient transportation access. All ofour products comply with international quality standards and are greaappreciated in a variety of different ChengDu markets throughout the worlde have over50 employees, an annual sales figat exceeds USD6000000 and are currently exporting20% of our production worldwide.Ourwquipped facilities and excellent quality control throughout all stages of productionabto guarantee total customattactionAs a result of our high quality products and outstanding customer service, we have gained a global sales network reaching(Indonesia.Southeast Asia.South Asia.Africa.Russia.Middle East)you are interested in any of our products or would like to discuss a custoorder, please feel free to contact us.e looking forward to forming successfubusineselationships with new clients around the world in the near future.


Certifications




Packing and shipping




FAQ


Q1.What kind payment method we accept?

A1.T/T, Western Union, Trade Assurance on Alibaba, Moneygram .

Q2.How can you guarantee payment safety ?

A2.Our company supports TRADE ASSURANCE service. If you will choose payment through ALIBABA TRADE ASSURANCE
service, you payment will be guaranteed. Because we are not able to receive payment until you confirm goods receipt.

Q3.What kinds of shipment for goods and how long time it takes ?

A3.Our company supports DHL, FEDEX, UPS, TNT, CHINA POST, by sea,by air and other methods. Shipping time is 3-5 days after the paments are received.

Q4.Does your company ship battery or not ?

A4.Our company can receive battery order and ship to customer normally, except for a few special countries

Q5.Do you have other items not displayed on your website ?

A5.Yes, our company supplies full range survey products. If you are looking for product not whowed on
our website. Please contact us freely. We will reply you in time.

Q6. Can you do a custom logo on the products?

A6. Yes. We can print your logo on our products and boxes.
