JHA series DA Pneumatic Rotary Actuator for ball valve color customizable
- Category: Pneumatic Parts >>>
- Supplier: Taizhou Juhang Automation Equipment Technology Co. Ltd.
Share on (1600318317025):
Product Overview
Description
Products Description
Compact Structure & Material
Rack and Pinion Quarter-turn pneumatic valve actuator. High quality aluminum alloy, the surface hard anodized + Teflon.
Service Life & Application
Low friction, long service life and the switching frequency is up to 1000000 times. The pneumatic actuator is being used for angular stroke valves, ball valves, butterfly valves and plug valves.
Operating Media | dry or lubricated air or non-corrosive gases |
Air Supply Pressure | 40 - 140psi (2-10bar) |
Operating Temperature | -35°C ~ +150°C |
Travel Adjustment | ±5° on each end of the rotation, at 0° and 90° |
Installation and Connection Flange | ISO5211/ DIN3337 |
Accessories Connections | NAMUR (VDI/VDE 3845) |
JUHANG Pneumatic Actuator
High-end products, excellent quality, complete certification system. All products are underwent a rigorous testing in our factory, each actuator are marked on the production code, easy identification and tracking service.
Drive and Flange to ISO5211 configuration for easy direct mount onto a valve or connnection with standardized mounting hardware.
Air supply connection is designed in accordence with NAMUR Standard to install solenoid valve.
The NAMUR Drive and NAMUR top mounting connection for direct installation of accessories such as Limit Switch and Positioner.
Quality detection
JUHANG does strict test to every product.
Inspectors are highly responsible in each component, with the most advanced testing equipment and strict scientific management to make every product can be endured to customers' picking. We promise every product which left our factory is up to the factory standard. It is also the recipe of salable for our products.
Factory workshop
We have advanced processing equipment: high-precision CNC machine tools, four-axis machining center with advanced technology, the accuracy in a harsh products are quaranteed.
Our product's quality taken from the advanced manufacturing methods, quality consciousness comes from constant innovation.
Our company also has a laboratory of high precision testing instruments. Sophisticated technology and strict quality management system, and gathered a professional team and technical elite and advanced level technology and make full use of new technologies, new processes, new materials to ensure product stability and reliability.
Our product's quality taken from the advanced manufacturing methods, quality consciousness comes from constant innovation.
Certifications
Customer Photos
Exhibition
Packing and Delivery
FAQ
Q1: What are your main products?
A1: Our main products are Pneumatic Actuators, Manual Actuator, Pneumatic Valves, Stainless Steel, Pneumatic Actuator and Parts of Actuator.
Q2: Are you a trading company or a manufacturer?
Q3: Do you have any exporting experience?
Q4: How long is your delivery time?
Q5: What are your main export countries?
Q6：Do you support sample service?
Q2: Are you a trading company or a manufacturer?
A2: We are manufacturers.
Q3: Do you have any exporting experience?
A3: Yes, we have a lot of export experience.
Q4: How long is your delivery time?
A4: Usually it takes 2~4 weeks on the production. For the sample it will takes 1~2 weeks.
Q5: What are your main export countries?
A5: USA, Turkey, Netherlands, Brazil, Dubai is our main export country.
Q6：Do you support sample service?
A6: Yes, we support.
