Full Automatic Pet Blow Machine Auto Bottle Blowing Machine
US $13000-$30000
2 Cavities Semi Automatic high efficiency plastic bottle making machine pet bottle blowing machine
- Category: Stretch Blow Moulding Machines >>>
- Supplier: Zhangjiagang,Longsn,Machine,Co.,Ltd.
Share on:
Product Overview
Description
Product Description
PET Bottle Blow molding Machine is applied for 10ml-2000ml small volume bottle production,Semi automatic bottle blow molding machine can produce PET containers including the bottles for kinds of wine, drink, soybean, vinegar, and pesticide (less than 5liters) according to the different bottle shape and diameter.
Features
1. Adopt the new type double bend arm and four pull rod-clamping structure (won the patent). Cross direction; middle mould board is move parallel; the distance between two mold bases is adjusted by the chain wheel. Thus, the clamping force is very strong.
2.The machine frame is produced by the whole complete casting bottom, so that the machine is firm and running stable.
3. Adopt the straight slide way, reduce the friction and lengthen the life of the machine.
4. Double start working button, which is designed for avoiding the injury.
5. Power saving design that can increase your profits.
6. The single direction of pre-form placing and bottle picking, which increase the output.
7. Segregate type air controlling system, which is designed for avoiding waste pollution.
8. The stretching air cylinder is adjusted parallel from front to back, from left to right freely by regulator.
Technical Parameter:
Type | Item | Unit | Description |
End product | Material | / | PET |
Volume | L | 0.05-2.5L(2cavity) 3-7L(1cavity) | |
Theoretical output | Pcs/hr | 0.05-2.5L:1000 3-6L:400 | |
Max. length | mm | 390 | |
Max. diameter | mm | 180 | |
Mould plate | Max. Mould plate dimension | mm | 420x500 |
Max. Mould thickness | mm | 160-240 | |
Clamping force | KN | 180 | |
Mould opening stroke (adjustable) | mm | 200 | |
Main body electricity | Power | KW | 10 |
Air compressor | kw | 15 | |
Voltage/frequency | V/Hz | 220-380/50-60 | |
Machine dimension and weight | Main body dimension (LxWxH) | cM | 153*60*200 |
Lengthened heater LxWxH) | cm | 180*110*140 | |
Main body weight | T | 0.6 |
Item | Name of the main spare parts | Brand Name |
1 | Closing cylinder | German FESTO |
2 | Stretching/sliding cylinder | German FESTO |
3 | Sealing sylinder | German FESTO |
4 | High Pressure Blowing cyliner | CHINA |
5 | Closing magnetic valve | German FESTO |
6 | Stretching magnetic valve | German FESTO |
7 | Sealing valve | German FESTO |
8 | Pre-blow magnetic valve | CHINA |
9 | Voltage regulator | CHINA |
10 | Temperature controller | CHINA |
11 | Computer controller | Bothfit |
12 | Infrared lamp | CHINA |
13 | Motor | CHINA |
14 | Relay | CHINA |
15 | Fan | CHINA |
16 | Circuit Breaker | CHINA |
Images:
Related products:
Packaging & Shipping
Our Services
Before the order:
We will make detailed solution for you based on your requirments.
We will send you videos of our products to know more about our machines.
If you are willing to visit our factory,we will pick you up at a nearby airport/station.
After the order:
We will start to produce machines and update the progress.
Our engineer will draw the layout for you.
After-sales service:
Arrange our engineer to your factory to install machines if you need,train your employee until they can operate machines well.
Provide you 2 years warranty with spare parts 2 year free.
24 hours for engineer response (all services part 5days in customer hand by Intl' courier)
Company Information
Zhangjiagang Longsn Machine Co., Ltd. is a professional manufacturer which integrating development, research, design, manufacturing, technical service and marketing to manufacture complete sets of Packaging machines .
Zhangjiagang Longsn Machine Co., Ltd. factory covers an area of 8,000 square meters, has more than 10 professional design and development teams, and more than 30 professional production and installation commissioning engineers. We adhere to the policy of "market-oriented, quality-oriented, service-guaranteed and reputation-based". Longsn Machines follows the ISO 9001:2000 international quality management system, establishes and improves the quality assurance system to ensure the quality and performance of the company's products.
FAQ
Q1:Are you a trading company or a manufacturer ?
A1:We are the manufacturer ,we produce machines ourselves,we can assure the quality.
Q2:What is your advantage?
A2:Competitive price , Excellent technical support ,24h online service
Q3:When can I get my machines after I paid?
A3:We will arrange delivery on time,act according to the contract.
Q4:What's your guarantee or the warranty of the quality if we buy your machines?
A4:We offer you high quality machines with 2 years guarantee . we will give u spare part free in 2 years
Q5:How can I install my machine when it arrives?
A5:We will provide 24 hours online service,if needed we will send our engineer to your side as soon as you get all your machines ready,for testing and teaching your technicians how to run the machines.
