JH21 25 ton C frame single crank pneumatic punching power press machine
- Category: >>>
- Supplier: Anhui Harting Machinery Technology Co. Ltd.
Share on (1600320794843):
Product Overview
Description
Product Description
JH21-25 ton C frame single crank pneumatic punching power press machine.
Main Features
1.The high-rigidity body is designed, the high-quality steel plate is used for welding, and the stability and reliability of the
precision of the whole machine are high by relieving the internal stress;
2.The precision machining is high, the noise is low, and the comprehensive clearance is low;
3.The symmetrical six- -face long guide rail of the sliding block is used for guiding, so that precision is high, and the
operation is stable;
4.The adjustment of the mold height is precision, safe, convenient and reliable;
5.The crankshaft, gear set, connecting rod and other components have high comprehensive performance and durability through the hard oxidization, grinding and other process treatment;
6.The closed high-rigidity body is designed, the high- -quality steel plate is used for welding, and the stability and reliability
of the precision of the whole. machine are high by relieving the internal stress;
7.The automatic thick oil lubrication system is available, so that it is convenient and accurate for supplying the oil; and the
oil line alarm function is provided, so as to ensure the smooth operation of the machine tool;
8.The structural design of the whole machine is reasonable, so as to be convenient for realizing the automatic production, reduce the cost, and improve the efficiency;
9.The advanced design philosophy is provided, the noise is low, the consumption is low, and the energy is saved.
1.The high-rigidity body is designed, the high-quality steel plate is used for welding, and the stability and reliability of the
precision of the whole machine are high by relieving the internal stress;
2.The precision machining is high, the noise is low, and the comprehensive clearance is low;
3.The symmetrical six- -face long guide rail of the sliding block is used for guiding, so that precision is high, and the
operation is stable;
4.The adjustment of the mold height is precision, safe, convenient and reliable;
5.The crankshaft, gear set, connecting rod and other components have high comprehensive performance and durability through the hard oxidization, grinding and other process treatment;
6.The closed high-rigidity body is designed, the high- -quality steel plate is used for welding, and the stability and reliability
of the precision of the whole. machine are high by relieving the internal stress;
7.The automatic thick oil lubrication system is available, so that it is convenient and accurate for supplying the oil; and the
oil line alarm function is provided, so as to ensure the smooth operation of the machine tool;
8.The structural design of the whole machine is reasonable, so as to be convenient for realizing the automatic production, reduce the cost, and improve the efficiency;
9.The advanced design philosophy is provided, the noise is low, the consumption is low, and the energy is saved.
Specification
ITEM | JH21-25 | ||
Nominal Capacity(KN) | 250 | ||
Slide Stroke(mm) | 80 | ||
Slide Strokes | Fixed(mm) | 100 | |
Variable(optional)(mm) | 60-100 | ||
Max. Die Shut Height (mm) | 250 | ||
Die Shut Height Adjustment (mm) | 50 | ||
Throat Depth (mm) | 210 | ||
Distance Between Columns (mm) | 450 | ||
Slide Bottom Size | F-B (mm) | 360 | |
L-R (mm) | 250 | ||
Shank Hole Size | Diameter (mm) | 40 | |
Depth (mm) | 65 | ||
Bolt distance | F-B (mm) | 980 | |
L-R (mm) | 690 | ||
Thickness (mm) | 80 | ||
Bed Opening Hole Diameter | 150 | ||
Overall Dimensions | F-B (mm) | 1496 | |
L-R(mm) | 945 | ||
Height(mm) | 2120 | ||
Motor Power(KW) | 3 | ||
Weight(approximate)(kg) | 2450 | ||
