Product Overview

Description













USB 3.0 Webcam 1920*1080 Sony IMX291 Mini Case CCTV Video USB Camera for Security Monitoring, Industrial Equipment








Features:










1080P USB 3.0 Camera Module with 3.6mm lens
1/2.8 SONY IMX291 Color CMOS Sensor for high quality image
High speed USB 3.0 interface for high resolution PC camera interface.
Super small outline 38*38mm and thin profile for embedded applications.
High frame rate– deliver 50 fps in 1920X1080 resolution.
UVC compliance for use in OS Windows, Linux, Android
OTG support









Specification
















































































































Model


ELP-SUSB1080P01-BL21 (2.1mm lens)
ELP-SUSB1080P01-BL28 (2.8mm lens)

ELP-SUSB1080P01-BL36 (3.6mm lens)

ELP-SUSB1080P01-BL60 (6mm lens)

ELP-SUSB1080P01-BL80 (80mm lens)

ELP-SUSB1080P01-BL12 (12mm lens)

ELP-SUSB1080P01-BL170 (170 degree fisheye lens)

ELP-SUSB1080P01-BL180 (180 degree fisheye lens)

ELP-SUSB1080P01-BL29 (2.9mm lens)

ELP-SUSB1080P01-BFV (2.8-12mm varifocus lens)



Sensor


IMX291


Lens Size


1/2.8 inch


Pixel Size


2.9µm X 2.9µm


Max. Resolution


1920(H)X1080(V)


Compression format


MJPEG / YUV2(YUYV)


Resolution & frame


1920X1080 MJPEG@ 50fps/ USB3.0 1920X1080 YUY2@ 50fps
1280X720 MJPEG@ 50fps / USB3.0 1280X720 YUY2@ 50fps
640X480MJPEG@ 50fps / USB3.0 640X480 YUY2@ 50fps


S/N Ratio


40dB


Dynamic Range


65dB


Sensitivity


1900mV/lux-sec@550nm


Mini illumination


0. 01lux


Shutter Type


Electronic rolling shutter / Frame exposure


Connecting Port type


USB3.0 High Speed


Free Drive Protocol


USB Video Class(UVC)


AEC


Support


AEB


Support


AGC


Support


Adjustable parameters


Brightness, Contrast, Saturation, Hue, Sharpness, Gamma,
Gain, White balance, Backlight Contrast, Exposure


Lens Parameter


HD 3.6mm M12 lens


Power supply


USB BUS POWER


Operating Voltage


DC5V


Working current


170mA~210mA


Working temperature


0~70℃


Board size /Weight


38*38mm


Cable


Standard 3M


Operating system request


Win8 and above
Linux with UVC(above linux-2.6.26)
MAC-OS X 10.4.8 or later
Android 4.0 or above with UVC





Application







Car and ship control, electronic equipment, oil field equipment, industrial equipment, remote site monitoring,environmental
monitoring, etc.
used for all kinds of machine as below:
machinery equipment, all-in-one machine, POS equipment, STB, smart box TV BOX, advisement player, LED display,automatic vending machine, safety box, notebook, video door phone, MID, Tablet external,evaluator, Medical Equipment, on-the-spot law enforcement, door bell and button system, cat-eye system, simple security system, teaching system, Interactive system, automobile data recorder. Project video capture, credit card machine, attendance machine, Voting system, High speed video shooting Device, exam system, Driving learning system, Industrial camera, biological microscope, box inside surveillance, micro HD surveillance,endoscope, Medical auxiliary equipment, etc.itable for producing PET plastic containers and bottles in all shapes.







Product Description







Camera with 2.1/2.8/2.9/3.6/6/8/12mm lens
























Camera with 170 degree Fisheye lens






















Camera with 180 degree fisheye lens






















Camera with 2.8-12mm Varifocus lens
