E commerce Wholesale 1310 & 1550 MINI TX GM TX13 FM Tuner
E-commerce Wholesale 1310 & 1550 MINI TX GM-TX13 FM Tuner
E-commerce Wholesale 1310 & 1550 MINI TX GM-TX13 FM Tuner

E commerce Wholesale 1310 & 1550 MINI TX GM TX13 FM Tuner

Share on (1600323840503):


Price:

Quantity:


Product Overview

Description



Products Description


INVISIBLE LASER RADIATION AVOID DIRECT EXPOSURE TO BE
1.Designed for FTTH(Fibor To The Home)networke
2.Excellent inearity and flatness
3.Smaller size and easier installatlon
4.Red-LED for power indication
5.Using mini DFB laser in coaxial packing
6.Singo- mode nber gh return oasA ueno Gaas anpl tor aatxf indent
ngth 3mw optieal power outptOTH. 10mw s1310mm wavelength, 10mm opical nower output
7.Singo- mode nber gh return oasA ueno Gaas anpl tor aatxf indent
ngth 3mw optieal power outptOTH. 10mw s1550mm wavelength, 10mm opical nower output


Item
Description
Customerinterface

RF Connector

F-female

Optical Connector

SC/APC

Power Supply

F-female
Optical Parameter

Optical Return Loss
≧45 dB
Output Optical Wavelength
1310 or 1550 nm
Output Optical Power
3 or 10 mW
Optical Fiber Type
Single Mode
RF Parameter
Frequency Range
47-1000 MHz
Flatness
±0.75dB
RF Input Level
80±5 dBuV
Input Impedance
75Ω
Return Loss
≧16 dB
CNR
≧52 dB
CSO
≧60 dB
CTB
≧63 dB
Other Parameter
Power Supply
12VDC
Power Consumption
<2W
Dimensions
168*103*40 mm
Input impedance (unbalance): 10kΩ
