Rugged RSR 2500 capacitor energy storage stud welder bolt label welder heat preservation nail type welder
- Category: >>>
- Supplier: Shenzhen Macex Industry Co. Ltd.
Share on (1600325212641):
Product Overview
Description
Product Description
High Capacity CD Stud Welding Machine
Compact, portable Capacitor Discharge equipment MACEX-RSR2500 designed to weld up to 10mm diameter studs. With its simple and robust construction the MACEX-RSR2500 range offers an economic and reliable method of fixing Mild Steel, Stainless Steel, Aluminium and Brass studs. Fast and accurate, the MACEX-RSR2500 range gives you better weld results. Designed and built to exacting standards and meets all required standards. Not only satisfy the welding of different metal materials, and meet the needs of different users using welding method.
Features
lCompact, lightweight portable machine.
lStrong, robust construction.
lRapid welding action reduces weld time.
lSuper fast recharge time improves profitability.
lEasy adjustment of capacitor voltage.
lLED displays allow easy monitoring of functions.
lWelds Mild Steel, Stainless Steel, Aluminium and Brass.
lQuality and reliability from TAYLOR Stud welding Systems Ltd.
lQuality assurance: monitoring and optimization of welding quality.
lStrong, robust construction.
lRapid welding action reduces weld time.
lSuper fast recharge time improves profitability.
lEasy adjustment of capacitor voltage.
lLED displays allow easy monitoring of functions.
lWelds Mild Steel, Stainless Steel, Aluminium and Brass.
lQuality and reliability from TAYLOR Stud welding Systems Ltd.
lQuality assurance: monitoring and optimization of welding quality.
Advantages
Weld Studs fasteners are used in a wide variety of industries:
lNo drilling or tapping
lNo cleanup
lNo cleanup
lWill not vibrate lose
lNo weld fillet
lReverse side can paint finished before welding
lParent base materials from .025” and up
lVery fast, 5-6 milliseconds
lWeld up to 50 studs per minute
lNo drilling or tapping
lNo cleanup
lNo cleanup
lWill not vibrate lose
lNo weld fillet
lReverse side can paint finished before welding
lParent base materials from .025” and up
lVery fast, 5-6 milliseconds
lWeld up to 50 studs per minute
Application
Weld Studs fasteners are used in a wide variety of industries:
lAerospace
lAppliances
lAutomotive
lConstruction
lElectronics
lForging Process
lInsulation Installation
lLight and Heavy Duty Equipment
lOffshore
lPetrochemical
lShipbuilding
lSigns and Decorative Trim
lToys
lTransportation
lUtilities Metalworking
lAerospace
lAppliances
lAutomotive
lConstruction
lElectronics
lForging Process
lInsulation Installation
lLight and Heavy Duty Equipment
lOffshore
lPetrochemical
lShipbuilding
lSigns and Decorative Trim
lToys
lTransportation
lUtilities Metalworking
Specification
ITEM | MACEX-RSR1600 | MACEX-RSR2500 | MACEX-RSR3500 | ||
Welding range | M3-M5 | M3-M8 | M3-M10 | ||
Welding Current | 300-1600A | 300-2500A | 300-3500A | ||
Welding Time | 0.1-3S | ||||
Welding speed | ∅20 10Pcs/min | ∅28 10Pcs/min | ∅32 10Pcs/min | ||
Input power | 380v±15%(3ph) | ||||
Rated Input power | 1.8kw | 2.5kw | |||
Capacitance | 72000uF | 108000uF | |||
Power Switch | 125A | 225A | 250A | ||
Protect Grade | IP23 | ||||
Cooling way | F | ||||
Dimension(L*W*H) | 250*250*470mm | 300*250*570mm | |||
Weight | 20kg | 30kg | |||
FAQ
Q: How to buy your products ?
A: We have some products in stock , you can take away the products after you arrange the payment ; If we don’t have the products in stock you want, we will start production once getting the payment.
Q: What’s the warranty for the products ?
A: The free warranty is one year from the date of commissioning qualified.
Q: Can we visit your factory ?
A: Of course, welcome to visit our factory if you come to China.
Q: How long is the validity of quotation ?
A: Generally, our price is valid within one month from the date of quotation. The price will be adjusted appropriately as the
price fluctuation of raw material in the market.
Q: What’s the production date after we confirm the order ?
A: This depends on the quantity. Normally, for the mass production, we need about one week to finish the production.
Please contact us for more detail information.
A: We have some products in stock , you can take away the products after you arrange the payment ; If we don’t have the products in stock you want, we will start production once getting the payment.
Q: What’s the warranty for the products ?
A: The free warranty is one year from the date of commissioning qualified.
Q: Can we visit your factory ?
A: Of course, welcome to visit our factory if you come to China.
Q: How long is the validity of quotation ?
A: Generally, our price is valid within one month from the date of quotation. The price will be adjusted appropriately as the
price fluctuation of raw material in the market.
Q: What’s the production date after we confirm the order ?
A: This depends on the quantity. Normally, for the mass production, we need about one week to finish the production.
Please contact us for more detail information.
