Hopewind 2.2kw solar water pump inverter super supplier

Product Overview

Description

Factory Price Single Phase MPPT Controller 220-240V 0.4KW 0.75KW 1.5KW 4KW Hybrid Solar Water Pump Inverter



Specifications:

Model: HW100-2S
Max Input DC Voltage	450V DC
Recommended MPPT Voltage Range	250~350V DC
Recommended Input Voltage  (Vmpp)	300~330V DC
MPPT Efficiency	99.90%
Rated Output Voltage	1AC or 3AC 220~240V
Output Frequency Range	0~600Hz
Effiency of the Inverter	97%
IP Grade	IP20
Water Level Control Function	Low water level start, High water level stop
Simple & Easy
High efficiency MPPT
Fully automatic running
Perfect pump protection
Water level control
Output: 1AC or 3AC 220V~240V



Options:

Model Selection:	Single Phase 220-240V Output
Model No.	Rated output power (kW)	Max. DC input current       (A)	Rated output current (A)	Pump (kW)
HW100-2S-0.4B	0.4	4.5	2.5	≤0.2
HW100-2S-0.7B	0.75	8.2	4	≤0.4
HW100-2S-1.5B	1.5	14	7	≤0.75
HW100-2S-2.2B	2.2	23	9.6	≤1.5
HW100-2S-4.0B	4	35	17	≤2.2



More Product Pictures:
