HP201 Torch Height Controller THC
- Category: >>>
- Supplier: Meisar (Changzhou) Intelligent Technology Co. Ltd.
Share on (1600337027263):
Product Overview
Description
Product Description
HP200 Plasma arc voltage automatic control system
High performance microprocessor as the core, the large screen LCD display interface, high voltage isolation amplifier.
Panel operation function is rich, arcing tests can be performed, the localization testing, cutting torch up and down, and so on.
Perforation, intelligent arc pressure adjustment, arc voltage protection function and extend the service life of wearing parts.
Display language can switch in both Chinese and English
Display control state at the same time, set the arc pressure and the actual arc pressure, real-time tracking.
Simple operation, a variety of adjustable parameters, better matching of different institutions.
Close to switch, protective cap, torque current, a variety of optional positioning way.
With functions of cutting torch collision prevention and 3d collision device is optional.
High performance microprocessor as the core, the large screen LCD display interface, high voltage isolation amplifier.
Panel operation function is rich, arcing tests can be performed, the localization testing, cutting torch up and down, and so on.
Perforation, intelligent arc pressure adjustment, arc voltage protection function and extend the service life of wearing parts.
Display language can switch in both Chinese and English
Display control state at the same time, set the arc pressure and the actual arc pressure, real-time tracking.
Simple operation, a variety of adjustable parameters, better matching of different institutions.
Close to switch, protective cap, torque current, a variety of optional positioning way.
With functions of cutting torch collision prevention and 3d collision device is optional.
Specification
Input Voltage: | DC24V±10% |
Lifter Motor: | DC24V Motor Max 40W |
Tracking Accuracy: | ±1V~5V Adjust |
Size/Weight: | 225mm*80mm*50mm, 1kg |
IHS Type: | Proximity switch |
Features: | AVR core, Rich function, 2EDG plug |
Isolation Type: | Inside ArcV Isolate, Power circuit, I/O port |
Function: | LCD display, Panel test, I/O Part definition |
