GGD AC Low Voltage Electrical Power Distribution Switch Cabinet / Switchgear Panel
- Category: >>>
- Supplier: Shanghai Linglan International Trading Co. Ltd.
Share on (1600343554608):
Product Overview
Description
Product Description
1.GGD type LV low voltage distribution cabinet is suitable for three-phase AC 50HZ, max voltage 380V, rated current to 3150A power distribution system , it is widely used in power plants, substations, industrial and mining enterprises etc energy consumer and using for power, lighting and distribution equipment for electrical energy conversion, distribution and control purposes.
2.Protection grade is IP30. IP20-IP40 could be optional according to the requirements of service condition.
3.Good appearance. easy assembly and disassembly
Working Environment
1.Ambient air temperature: -5℃~+40℃ and the average temperature should not exceed +35℃ in 24h
2.Indoor altitude above sea level: Maximum installation altitude: 2000m
3.Relative humidity should not exceed 50% at max temperature +40℃. Higher relative humidity is allowed at lower temperature. Ex. 90% at +20℃. But in view of the temperature change, it is possible that moderate dews will produce casually.
4.No fire, explosion danger, serious pollution, chemical corrosion and severe vibration
5.Installation gradient not exceed 5°
6.The equipment shall be installed in a place where there is no violent vibration and impact, and the place where the electrical components are not corroded.
2.Protection grade is IP30. IP20-IP40 could be optional according to the requirements of service condition.
3.Good appearance. easy assembly and disassembly
Working Environment
1.Ambient air temperature: -5℃~+40℃ and the average temperature should not exceed +35℃ in 24h
2.Indoor altitude above sea level: Maximum installation altitude: 2000m
3.Relative humidity should not exceed 50% at max temperature +40℃. Higher relative humidity is allowed at lower temperature. Ex. 90% at +20℃. But in view of the temperature change, it is possible that moderate dews will produce casually.
4.No fire, explosion danger, serious pollution, chemical corrosion and severe vibration
5.Installation gradient not exceed 5°
6.The equipment shall be installed in a place where there is no violent vibration and impact, and the place where the electrical components are not corroded.
Type | Rated Voltage | Rated current (A) | Rated short circuit break current(KA) | Rated short time withstand current (1s) KA | Rated peak withstand current (1s)KA |
GGD1 | 380 V | A.1000 | 15 | 15 | 15 |
B.600(630) | |||||
C.400 | |||||
GGD2 | 380V | A.1500 (1600) | 30 | 30 | 63 |
B.1000 | |||||
C.600 | |||||
GGD3 | 380V | A.3150 | 50 | 50 | 105 |
B.2500 | |||||
C.2000 |
Company Profile
FAQ
1.Does your products support OEM ?
Yes. we accept OEM order.
2.How do I order customized enclosures?
The customized product will be designed and made as per your your drawing or sample. When the customized sample can fully meet your requirements, we will start mass production.
3. What are leading times of orders?
The leading time is 20 days for 20GP container, and 30 days for 40 HQ container.
The customized product will be designed and made as per your your drawing or sample. When the customized sample can fully meet your requirements, we will start mass production.
3. What are leading times of orders?
The leading time is 20 days for 20GP container, and 30 days for 40 HQ container.
5. What is your payment mode ?
L/C at sight, T/T , Paypal, west union is acceptable.
