Bulletin Model
|
EQ6731LTN
|
Use
|
Passenger buses, tour buses, group buses
|
Body length
|
7320mm
|
Body width
|
2250mm
|
Body height
|
2850,3060mm
|
Vehicle mass
|
5200,5400kg
|
Total quality
|
8000 kg
|
Body structure
|
non-bearing type
|
Seating
|
24 to 31
|
Maximum speed
|
100km/h
|
Air conditioning system
|
Optional Pine overhead air conditioning, 15KW
|
Audiovisual system
|
MP3 player, optional MP4 or MP5 car hard disk player, manual folding display
|
Auxiliary configuration
|
defroster 24V,130W(optional 170W), ordinary seats (24 seats), anti-scraping electric wiper, front and rear combined lamps, half-width sunshade, model 700 skylight, electric fan, endoscope, fire extinguisher
|
Engine
|
NQ140BN5, YC4D140N - 50
|
Engine power
|
103,103kW
|
Displacement
|
3759421 4 mL
|
Engine brand
|
Geely Sichuan Commercial Vehicle Co., LTD., Guangxi Yuchai Machinery Co., LTD
|
Emission standard
|
GB11340-2005,GB18285-2005,GB17691-2005 country 5
|
Chassis model
|
EQ6690KN5AC Third Class Dongfeng Motor Co., LTD
|
Front and rear suspension
|
1220/2300mm
|
Number of springs
|
9/11
|
Transmission
|
5+1 gear, optional 6+1 gear, soft shaft wire drawing type control
|
Clutch
|
single piece dry 330mm, 350mm(YC4D), hydraulic remote control, air power
|
Shaft number
|
2
|
The wheelbase
|
3800 mm
|
Axle weight
|
2900/5100 kg
|
Before the track width
|
1854 mm
|
After the track width
|
1628 mm
|
Angle of approach departure
|
16/12°
|
Tyre number
|
6
|
Size
|
8.25-16,8.25 R16, 8.25-16 lt, R16LT 8.25, 9.5 R17.5
|
|
