Wireless Barcode Scanner with Cradle, 2D Cordless Bar Code Reader 400m industrial scanner reader industrial barcode scanner (1600344734730)

Share on:


Price:
Price in USD:Details

Quantity:


Product Overview

Description









ZD 6820HD
ZD 4125
ZD 4520


Physical Parameters
Input Voltage
DC5V , ±0.25V
Indicator
Buzzer & LED Indicator
Interface
USB, RS232, USB-COM
Performance Parameters
Module
2D Imager 1280*960
Code Contrast
≥25%
Resolution
≥3mil, Linear 2500pixels
Handset memory
Built-in storage for over 10,000 pieces of code data
Codes range
1D, 2D, DPM, monitor-displayed
2D Code types
QR Code, MicroQR, Data Matrix, PDF417, Micro PDF417, Aztec, Maxicode etc.
1D Code types
UPC-A, UPC-E,EAN-8, EAN-13, EAN-ISBN/ISSN, Code 39, Code 39(Full ASCII), Industrial 2 of 5, Interleave 2 of 5, Matrix 2 of
5,Codabar, Code 128, Code 93, Code 11 MSI/Plessey, UK/Plessey, UCC/EAN 128, China Post Code, GS1 Data Bar (formerly RSS) etc.
Angle Tolerance
Skew ±60°, Pitch ±70°, Roll 360°
Mode setting
Set by scanning functional Code
Shock Resistance
Withstand multiple drops from 2m to comcrete surface
Dust & Water proof
IP68
Environment Parameters
Environment Temperature
-18°C ~55°C (working); -40°C ~60°C (storage)
Environment Humidity
5~90% (Non-condensing)
Environment Luminance
0 ~ 100,000 Lux
Certification
CE RoHS FCC
