Good Quality 6N.m Rated Torque Textile Machinery Components Micro Electricagnetic Clutch 24V
Good Quality 6N.m Rated Torque Textile Machinery Components Micro Electricagnetic Clutch 24V
Good Quality 6N.m Rated Torque Textile Machinery Components Micro Electricagnetic Clutch 24V
Good Quality 6N.m Rated Torque Textile Machinery Components Micro Electricagnetic Clutch 24V
Good Quality 6N.m Rated Torque Textile Machinery Components Micro Electricagnetic Clutch 24V
Good Quality 6N.m Rated Torque Textile Machinery Components Micro Electricagnetic Clutch 24V
Good Quality 6N.m Rated Torque Textile Machinery Components Micro Electricagnetic Clutch 24V

Good Quality 6N.m Rated Torque Textile Machinery Components Micro Electricagnetic Clutch 24V

Share on (1600344978271):


Price:$90.00 - $100.00

Quantity:


Product Overview

Description









Model
MCS-006
MCS-015
MCS-025
MCS-050
MCS-100
MCS-200
MCS-400
Static friction torque[kgf-m] (N-m)
0.6(6)
1.5(15)
2.5(25)
5.0(50)
10(100)
20(200)
40(400)
Kinetic friction torque[kgf-m] (N-m)
0.5(5)
1.0(10)
2.0(20)
4.0(40)
8(80)
16(160)
32(320)
Powder [DC24V] (W) at20℃
11
15
20
25
35
45
60
Weight(kg)
1.0
1.5
2.5
4
7
11
21
Maximum speed (r/min)
1800
Radius
A1
63
80
100
125
160
200
250
A2
46
60
76
95
120
158
210
A3
34.5
41.5
51.5
61.5
79.5
99.5
124.5
B
67.5
85
106
133
169
212.5
264
C
67.5
85
106
133
169
212.5
264
D
12
15
20
25
30
40
50
F
20
25
30
40
50
65
80
H
24
26.5
30
33.5
37.5
50
65
K
2
2
2
2
3.2
3.2
4
L1
31
34.5
39.5
44.5
50.5
60.5
77.5
L2
28
31
36
40.5
46.5
55.5
64
M
27
29.5
34
37.5
42
50
65
P
7.5
8
9
9
11.5
12.5
13
V1
3-3.1
3-4.1
3-5.1
3-6.1
3-8.1
3-10.2
4-12.2
V2
6.3
8
10.5
12
15
18
18
V3
5
6.2
8
10
13
15
16
X
1
1.2
1.5
1.8
3.2
3.5
4
a
0.2(±0.05)
0.3(+0.05,-0.1)
0.5(-0,-0.15)
shaft
G1
42.5
57.5
62.5
77.5
100
115
140
G2
50
65
70
85
112
135
160
G3
9.5
10.5
11.5
11.5
18.5
20
20
Y1
4.5
5.5
6.5
6.5
9
10.5
10.5
Y2
14
16
16
16
25
36
40
b
4
5
5
7
7
10
12
t
1.8
2.3
2.3
3.3
3.3
3.8
3.8


Advantages:
1. High speed response: because it is dry type, the transmission of torque is fast and convenient.
2, durability: good heat dissipation, and the use of advanced materials, even high frequency, high energy use, but also very
durable.
3. Easy assembly and maintenance: the magnetic field coil in the ball bearing is static, so there is no need to remove the core or use the carbon brush. It is easy to use.
4. The action is indeed: the use of plate shrapnel, although there is a strong vibration will not produce loose, good durability.
